VAM² SL 8.7

Geometry Specification
N/A
Sku Number
FO5400058v2024

VAM² SL 8.7 Features

Carbon frame

SR Suntour Raidon 34 fork & Rock Shox Deluxe Select+ shock

Shimano Deore 12-speed

When efficient meets playful

  • Light and slim frame design

    The VAM² SL 8.7 is engineered with a flex pivot rear triangle that combines optimal flex behaviour with a lightweight carbon layup. The efficient but playful bike character will make you pace up hills while also giving you courage to descend fast due to the e-MTB's downhill capabilities. With our new flex pivot design, we were able to reduce the amount of frame material, bearings, and bolts. This results in our lightest e-MTB frame: the 8. series frame weighs 2,545 g (size M, including linkage and bolts). On top, it gives the rear triangle its seamless look. The clean design of our VAM² SL 8.7 continues at the down tube, as the fully integrated battery ensures a slim look while further reducing weight.

  • Training made easy and fun

    Thanks to the e-drive, you will ride more trails in the same time. With its 125 mm suspension platform and direct handling, the VAM² SL 8.7 makes you enjoy and ride your trails in a new way, more like being on a giant pump track. The result: better riding skills and endless fun. Besides, you can make most of the FAZUA system by connecting it with your bike computer. It allows you to monitor cadence and power output for purposeful training. Combined with the efficient e-support, it is easier than ever to precisely ride at your performance threshold, keeping your heart rate at the perfect level for aerobic training sessions. You don't want or need any rest days but will find yourself riding on days that would usually keep you away from it.

  • Efficient FAZUA e-drive

    The light and efficient FAZUA Ride 60 makes you feel like having your legs best day. With 60 Nm torque and a maximum power output of 450 W, it pushes you forward while providing the feeling of a natural ride with minimal noise distractions. The drive system features three riding modes and an additional boost function that briefly increases the power output. You can also individualize the motor support via the FAZUA App by setting parameters like Max Power, Support Relation and Ramp-up based on your preferences. The integrated battery can be charged via the charging port at the seat tube. You will be surprised how far 430 Wh will take you. Worst case, the VAM² SL’s efficiency and lightweight also allow you to pedal home with an empty battery.

Geometry

S M L XL
Size in mm 390 420 440 460
Handlebar width 800 800 800 800
Stem length 50 50 50 50
Crank length 165 165 165 165
Seatpost length 390 440 480 480
A Seat tube length 390 420 440 460
B Top tube length 576 606 635 670
C Head angle (°) 66.5 66.5 66.5 66.5
D Seat angle (°) 75.5 75.5 75.5 75.5
E Chainstay length 440 440 440 440
F Bottom bracket drop 35 35 35 35
G Head tube length 100 100 120 140
H Fork length 541 541 541 541
I Fork offset 44 44 44 44
J Wheelbase 1166 1185 1218 1256
K Stack 602 602 620 639
L Reach 420 450 475 505
M Standover height 790 790 790 790
S M L XL
Size in mm 390 420 440 460
Handlebar width 800 800 800 800
Stem length 50 50 50 50
Crank length 165 165 165 165
Seatpost length 390 440 480 480
A Seat tube length 390 420 440 460
B Top tube length 576 606 635 670
C Head angle (°) 65.5 65.5 65.5 65.5
D Seat angle (°) 75.5 75.5 75.5 75.5
E Chainstay length 440 440 440 440
F Bottom bracket drop 35 35 35 35
G Head tube length 100 100 120 140
H Fork length 541 541 541 541
I Fork offset 44 44 44 44
J Wheelbase 1155 1196 1229 1267
K Stack 602 602 620 639
L Reach 420 450 475 505
M Standover height 790 790 790 790

Specification

Frame
Carbon technology frame, 125mm F.O.L.D. GEN3 kinematics, 148x12 thru axle, internal cable routing, Post Mount 180 mm
Fork
SR Suntour Raidon 34, 110x15 mm, 44 mm rake
Travel of suspension fork
130 mm
Shock
Rock Shox Deluxe Select+, 210/50 mm, hardware: 25.0 x 8.0 mm, no Bushing
Motor
Fazua Ride 60, 60 Nm, 430 W max.
Battery
Fazua 36V (430Wh)
Display & Remote
Fazua LED Hub + Ring Control
Shifter
Shimano Deore M6100, 12-speed
Rear derailleur
Shimano Deore M6100, 12-speed
Cassette
Shimano Deore CS-M6100, 12-speed
Chain
Shimano Deore CN-M6100, 12-speed
Crankset
Samox EC38 ISIS
Transmission of drive
front: 32, rear: 10-51
Chainring
Shimano Deore CS-M6100, 12-speed
Bottom bracket
Integrated in Drive Unit
Handlebar
Aluminium, 800 mm, rise: 30 mm, backsweep: 9°
Grips
VP VPG-122A
Stem
FOCUS C.I.S. 50 mm, 0°, 35 mm, aluminium
Headset
ACROS ZS56/ZS56 (ICR), FOCUS C.I.S. Integrated, 1.5/1.5" angle headset
Saddle
fi'zi:k Taiga
Seatpost
Post Moderne dropper post PM-MT171, 31.6 mm
Brakes front | rear
Magura MT Trail, front: 4-piston | Magura MT Trail, rear: 2-piston
Front brake disc
180 mm
Rear brake disc
180 mm
Rim front
RaceFace ARC27, 622-27, 32H
Rim rear
RaceFace ARC27, 622-27, 32H
Front hub
Shimano MT410, 15x110 mm
Rear hub
Shimano MT410, 12x148 mm
Spokes
Niro, black
Tyres front | rear
Maxxis Dissector, TR, EXO, 29 x 2,4" | Maxxis Rekon MAX, EXO, 29 x 2,4"
Weight
19.1 kg (430 Wh)
Permissible system weight
135 kg
* Subject to technical modification without notice. Errors and omissions excepted. ** Weight in size M, of standard specification and without pedals.
