360

PARALANE 8.8

Geometry Specification
N/A
Sku Number
FO0100015v2024

PARALANE 8.8 Features

Durable carbon frame (1,130 g)

Electronic SRAM Rival eTap AXS 2x12 shifting

DT Swiss E 1800 wheels

Takes you further

  • Durable carbon frame

    Ride it, enjoy it! The PARALANE opens up a new dimension of road cycling for us! The durable carbon road bike, even though it calls endurance home, also impresses in terms of speed and aerodynamics. Your fast yet versatile daily companion all year round. At your pace and on your route – whatever that may be. The PARALANE'S durable carbon frame tips the scale at 1,130 grams (size M). With an approved system weight of 120 kg, it is also well-suited for your fast-paced bikepacking adventure.

  • Endless possibilities with 35 mm tyre clearance

    All PARALANE models come with 32 mm road tyres. Making you peacefully float over pothole-littered roads and even the roughest of cycle paths in case you have to. Some say you could even conquer some gravel roads with it. If you want, you can fit tyres as wide as 35 mm, which takes off the pressure of your Komoot road planning. The frame is designed around a standard round 27,2 mm seat post to give you all options to dial in your perfect fit. Beyond that, our refined C.I.S. road stem is available in six lengths from 70 to 120 mm, and switching between them is more convenient than ever without opening any brake lines.

  • Extras for your comfort

    The PARALANE is designed to take you further. That's why there are special extras and a fender set to retrofit for the PARALANE. It comes with a bag on the top tube to ensure that you are always well nutritioned on long rides. Additionally, we include a dedicated frame protection sticker sheet with all models, if you want to protect the PARALANE's durable frame even further. We also designed a dedicated fender set (Art. nr. 311048800) that doesn't ruin a road bike's look or speed. You can buy it at your local FOCUS dealer. To learn more about the dedicated fender set, check out the FAQ on the PARALANE family page.

Geometry

XS S M L XL
Size in mm 480 510 540 570 600
Handlebar width 400 400 420 420 440
Stem length 80 90 110 110 110
Crank length 170 170 172.5 172.5 175
Seatpost length 350 350 350 350 350
A Seat tube length 455 485 505 535 575
B Top tube length 511 530 549 568 597
C Head angle (°) 70.5 71 72 72 72.5
D Seat angle (°) 75 74.5 74 73.5 73
E Chainstay length 415 415 415 415 415
F Bottom bracket drop 75 75 75 75 75
G Head tube length 124 144 164 189 219
H Fork length 382 382 382 382 382
I Fork offset 50 50 50 50 50
J Wheelbase 989 999 1004 1017 1036
K Stack 535 556 579 603 633
L Reach 368 376 383 389 403
M Standover height 747 762 779 795 814

Specification

Frame
Carbon technology frame, disc, BSA, 142x12 mm thru axle, flat mount 160/160 mm, internal cable routing
Fork
Paralane Carbon disc, integrated cable routing, disc, 100x12 mm, flat mount
Shifter
SRAM Rival eTap AXS, 12-speed
Front derailleur
SRAM Rival eTap AXS, 12-speed
Rear derailleur
SRAM Rival eTap AXS, 12-speed
Cassette
SRAM XG-1251, 12-speed
Chain
SRAM Rival AXS, 12-speed
Crankset
SRAM Rival AXS, 12-speed
Transmission of drive
front: 50/34, rear: 11-34
Bottom bracket
SRAM DUB BSA 68
Handlebar
BBB Basic, aluminium, drop: 125 mm, reach: 70 mm
Grips
FOCUS Bartape SL
Stem
FOCUS C.I.S. 2.0 integrated, 31.8 mm, aluminium
Headset
ACROS, IS 52/40-IS52/42
Saddle
Selle Royal Groove SRX
Seatpost
BBB FlyPost SP-135, 27,2mm, carbon, set-back: 15 mm
Brakes front / rear
SRAM Rival eTap AXS, 12-speed / SRAM Rival eTap AXS, 12-speed
Front brake disc
160 mm
Rear brake disc
160 mm
Wheelset
DT Swiss E 1800, alloy, 622-23, 12x100 mm / 12x142 mm, 30 mm height
Tyres front / rear
Vittoria Zaffiro Pro, 700 x 32C, Folding / Vittoria Zaffiro Pro, 700 x 32C, Folding
Weight
9.1 kg ()
Permissible system weight
120 kg
* Subject to technical modification without notice. Errors and omissions excepted. ** Weight in size M, of standard specification and without pedals.
