AVENTURA² 6.9

Geometry Specification
N/A
Sku Number
FO5080083v2024

AVENTURA² 6.9 Features

BOSCH CX e-drive & 750 (size S: 625) Wh battery

SR SUNTOUR Raidon LOR fork, 4-piston brakes and 130 Lux light

SHIMANO XT 1x12 shifting

Awakens your inner explorer

  • Super powerful and dynamic e-motor

    The efficient Bosch Performance CX e-drive (Gen. 4) supports your ride up to 25 km/h with powerful 85 Nm. A well-balanced geometry makes the AVENTURA² 6.9 ride agile and dynamic. The strongest e-motor of Bosch is perfectly integrated into the bottom bracket area.

  • Record-breaking range and easy-to-read display

    The new Bosch Powertube battery (smart system) with its record-breaking 750 Wh (size S: 625 Wh) is perfectly integrated into the down tube, yet it can also be removed at any time for charging. By adding a DualBattery or a PowerPack, you can also have up to 1.475 Wh (not possible for size S). Furthermore, the Kiox 300 offers a big and easy-to-read display with remote and great ergonomics. Additionally, a USB-C port on the top tube gives you the opportunity to charge your devices.

  • Ready for anything

    Regardless of whether your journey lasts several days or you simply need to transport a lot of belongings: with its pannier rack, fenders, kickstand, lock mount and light, the AVENTURA² 6.9 is equally well-prepared for bikepacking trips and transporting heavy loads across the city. You can choose between a wave or a diamond frame: Easy to step in and out or more sportive – we have the frame shape you prefer. On top, the AVENTURA² 6.9 is approved for most trailers and for a system weight (rider plus gear and bike) of 150 kg. The ergonomic cockpit with a 30-degree stem and wide off-road tyres make your ride comfortable even off the beaten track. The C.I.S. (Cockpit Integration Solution) technology offers a clean cockpit with cable routing through stem and headset into the frame.

Geometry

S M L XL
Size in mm 400 440 480 520
Handlebar width 760 760 760 760
Stem length 90 90 90 90
Crank length 170 170 170 170
Seatpost length 350 350 350 350
A Seat tube length 400 440 480 520
B Top tube length 594 615 638 662
C Head angle (°) 67 68 68 68
D Seat angle (°) 74 74 74 74
E Chainstay length 470 470 470 470
F Bottom bracket drop 65 65 65 65
G Head tube length 130 130 140 160
H Fork length 515 515 515 515
I Fork offset 51 51 51 51
J Wheelbase 1175 1180 1209 1211
K Stack 642 644 653 672
L Reach 410 430 450 470
M Standover height 808 820 838 860

Specification

Frame
7005 hydroformed aluminium, 3D forging, 148x12 mm thru axle, USB-C port, post mount 180 mm
Fork
SR Suntour Raidon 34 LOR AIR, 110x15 mm
Travel of suspension fork
100 mm
Motor
Bosch Performance CX Smart, 85 Nm, 250 W
Battery
Bosch 625 Intube (625Wh),Bosch PowerTube Li-Ion (750 Wh)
Display & Remote
Bosch LED Remote + Kiox 300
Shifter
Shimano Deore M6100, 12-speed
Rear derailleur
Shimano Deore XT M8100, 12-speed
Cassette
Shimano Deore CS-M6100, 12-speed
Chain
Shimano Deore CN-M6100, 12-speed
Crankset
FSA CK-320, aluminium
Transmission of drive
front: 36, rear: 10-51
Chainring
Shimano Deore CS-M6100, 12-speed
Bottom bracket
Integrated in Drive Unit
Handlebar
Aluminium, 690 mm, rise: 8 mm, 31,8 mm
Grips
Herrmans Click
Stem
Aluminium, adjustable, 90 mm
Headset
ACROS ZS56/ZS66 (ICR), FOCUS C.I.S. Integrated
Saddle
Selle Royal Vivo
Seatpost
Aluminium, 31.6 mm
Brakes front | rear
Shimano MT420 | Shimano MT420
Front brake disc
200 mm
Rear brake disc
180 mm
Rim front
RODI TRYP25, 25-622
Rim rear
RODI TRYP25, 25-622
Front hub
Shimano TC500, 15x110 mm
Rear hub
Shimano TC500, 148 x 12 mm
Spokes
Zink, black
Tyres front | rear
Schwalbe Smart Sam , 29 x 2,25" | Schwalbe Smart Sam , 29 x 2,25"
Fenders
Büchel, aluminium, 60 mm, powder-coated
Headlight
Litemove AE130, high-beam, 130 LUX
Rear light
TRELOCK LS421, Brake light
Rear rack
Racktime Snap-It carrier, 2-leg, 25 kg max. load
Kickstand
rear stand, adjustable
Weight
26.6 kg (625 Wh),26.6 kg (750 Wh)
Permissible system weight
150 kg
* Subject to technical modification without notice. Errors and omissions excepted. ** Weight in size M, of standard specification and without pedals.
