FOCUS SAM² 6.7 Features
Tailored Energy Concept (T.E.C.) with up to 760 Wh battery power
RockShox Yari RC suspension fork and RockShox Deluxe R shock
Sram NX Eagle 1x12 drive with wide gear ratio range
Designed for down
-
Always as much energy as you need
With the quick and easy-to-install T.E.C. Pack, you will have up to 756 Wh at your disposal for long tours. Or you could use the Smart Rack to store your equipment and a bottle on the down tube. Meets your every need.
-
Optimal suspension performance in any situation
Our F.O.L.D. chassis has been specially designed to meet the increased demands placed on e-MTBs. This means that we can also guarantee the perfect mix for the e-Enduro FOCUS SAM²: F.O.L.D. is extremely sensitive while being progressive enough to prevent a harsh bottom out.
-
Handling characteristics matter
Thanks to the compact design of the Shimano E8000 motor and our battery, we have succeeded in creating a geometry for the FOCUS SAM² that is modern, agile and aggressive – just like its sporty 27.5" wheels. This means that you will have just as much fun out on the trail as with our non-electric FOCUS SAM.
Geometry
| S | M | L | ||
|---|---|---|---|---|
| Size | 42 | 44 | 48 | |
| Seat tube length | ||||
| Handlebar width | 780 | 780 | 780 | |
| Stem Length (MM) | 55 | 55 | 55 | |
| Crankarm length | 165 | 165 | 165 | |
| A | Size (MM) | 420 | 440 | 480 |
| B | Effective Top Tube (MM) | 585 | 604 | 624 |
| C | Head Tube Angle (°) | 65 | 65 | 65 |
| D | Effective Seat Tube Angle (°) | 75 | 75 | 75 |
| E | Chainstay length (MM) | 455 | 455 | 455 |
| F | Bottom bracket drop (MM) | 12 | 12 | 12 |
| G | Head Tube Length (MM) | 118 | 118 | 138 |
| H | Fork construction height (MM) | 562 | 562 | 562 |
| I | Pre-raked fork (MM) | 42 | 42 | 42 |
| J | Wheelbase length (MM) | 1196 | 1217 | 1240 |
| K | Stack (MM) | 607 | 607 | 625 |
| L | Reach (MM) | 425 | 440 | 455 |
Specification
Frame material
Aluminium
Frame
7005 hydroformed aluminium, 3D forging, 170 mm F.O.L.D. kinematic, 148x12 mm thru axle, internal cable routing, post mount 180 mm
Fork
Rock Shox Yari RC, 110x15 mm QR, 170 mm travel
Travel Fork
170 mm
Shock
Rock Shox Deluxe R, 230/65 mm, hardware: 25,0 x 8mm, custom tune
Motor
Shimano Steps E8000, 70 Nm, 250 W
Battery Watt-hours
378 Wh
Battery Ampere hours
10,5 Ah
Display
Shimano Steps E8000, colored LCD display, walk assist, bluetooth
Shifter
SRAM NX Eagle
Rear derailleur
SRAM NX, 12-speed
Sprocket
SRAM PG-1230 Eagle, 12-speed
Chain
SRAM NX Eagle
Crankset
FC-E8000-34T
Transmission of drive
front: 34, rear: 10-50
Handlebar
BBB, aluminium, Di2, riserbar, 780mm, rise: 20mm, backsweep: 9degree
Grips
FOCUS Locker SL
Stem
BBB, aluminium, Di2, 31.8 mm, 55 mm
Headset
Acros BlockLock
Saddle
FOCUS Trail Saddle
Seatpost
KindShock E30i, 31,6mm, internal
Brakes
Magura MT5
Brake lever description
MAGURAMT5F1
Brake
Disc
Wheelset
Race Face AR30, 584-30, Novatec, 148x12 mm / 110x15 mm
Rims
RaceFace AR30 Offset
Rear hub
Novatec D162 Disc, 12x148 mm
Front Hub
Novatec D041, 15x110 mm
Tires
Maxxis DHF 2.6 3C EXO TR
Rear tire
Maxxis DHR II 2.6 Dual EXO TR
Gears
12
Size
48,42,44
* Subject to technical modification without notice. Errors and omissions excepted.
** Weight in size M, of standard specification and without pedals.
