Exemplary bike presentation. Actual parts are shown in the specifications list.
Supports your lifestyle
-
Less is more
Simplify, don’t overcomplicate things. This is your mantra. And this is why we have made operating the WHISTLER² as simple as possible. Simply switch it on and away you go.
-
Experience even more with the same amount of effort
Your everyday life is packed to the brim, so every minute counts when it comes to your hobbies. With the WHISTLER², you can get from A to B more quickly and with less stress. It offers 252 Wh to support your lifestyle.
-
Consistent braking performance
When faced with risky situations, you need a partner you can rely on. That is why we have equipped our WHISTLER² with disc brakes to ensure consistent braking performance and optimal braking behaviour.
Geometry
| XS | S | M | L | XL | ||
|---|---|---|---|---|---|---|
| Size | 38 | 42 | 46 | 50 | 54 | |
| Size (MM) | 380 | 420 | 460 | 500 | 540 | |
| Handlebar width | 700 | 700 | 700 | 700 | 700 | |
| Stem Length (MM) | 90 | 90 | 90 | 90 | 90 | |
| Crankarm length | 170 | 170 | 175 | 175 | 175 | |
| A | Seat tube length (MM) | 380 | 420 | 460 | 500 | 540 |
| B | Effective Top Tube (MM) | 553 | 575 | 587 | 608 | 623 |
| C | Head Tube Angle (°) | 69 | 70 | 70 | 70 | 70 |
| D | Effective Seat Tube Angle (°) | 73.5 | 74 | 74 | 74 | 74 |
| E | Chainstay length (MM) | 447 | 448 | 448 | 448 | 448 |
| F | Bottom bracket drop (MM) | 48 | 62 | 62 | 62 | 62 |
| G | Head Tube Length (MM) | 110 | 100 | 110 | 130 | 150 |
| H | Fork construction height (MM) | 497 | 517 | 516 | 516 | 516 |
| I | Pre-raked fork (MM) | 42 | 46 | 46 | 46 | 46 |
| J | Wheelbase length (MM) | 1073 | 1094 | 1106 | 1124 | 1145 |
| K | Stack (MM) | 602 | 628 | 637 | 655 | 675 |
| L | Reach (MM) | 375 | 395 | 404 | 420 | 430 |
Specification
Frame
6061 aluminium, BSA BB, international disc brake standard
Frame material
Aluminium
Fork
SR Suntour XCM RL, 9 mm QR
Travel Fork
100 mm
Motor
Groove Go, 250 W
Battery Watt-hours
252 Wh
Battery Ampere hours
7 Ah
Shifter
Shimano Altus M2000
Rear derailleur
Shimano Altus M2000, 9-speed
Sprocket
SHIMANO ACERA CSHG200 9-S 11-36T
Chain
KMC X9, 9-speed
Crankset
Samox AF38, 34T
Bottom Bracket
BSA
Transmission of drive
front: 34, rear: 11-36
Handlebar
Sport Riser, aluminium, risebar, 700mm, rise: 20mm
Grips
Velo VLG-975
Stem
aluminium, 31.8mm
Headset
VP Components
Saddle
FOCUS Sport Saddle
Seatpost
aluminium, 27,2mm
Brakes
Shimano BR-MT200, 180 mm / 160 mm
Brake lever
Shimano MT200
Brake
Disc
Wheelset
Rodi Viper 21, 27" 584-21, 29" 622-21, Shimano TX-505 CL, 9 mm QR / 9 mm QR
Rims
RODI Viper 21, 21-622
Rear hub
Groove Go, rearhub motor
Front Hub
Shimano TX505, QR
Tires
Schwalbe Rapid Rob 2.25
Gears
9
Size
54,42,46,38,50
* Subject to technical modification without notice. Errors and omissions excepted.
** Weight in size M, of standard specification and without pedals.
