PARALANE 5.9 GC

Geometry Specification
SKU
FO0120004v2019

PARALANE 5.9 GC Features

Lightweight Endurance aluminium frame with Comfort Improving Areas (C.I.A.), Curana mudguards for clever installation and R.A.T. floating axle

Simple and reliable in extreme situations: Sram Apex 1x11 gearshift

Lightweight Novatec N30 wheelset

Takes you further

  • More tyre clearance offers greater freedom

    The maximum tyre clearance of up to 35 mm gives you the freedom to ride on any type of surface – whether asphalt or gravel tracks.

  • Including quick-mounting mudguard

    Our sophisticated solutions make it quick and easy to mount mudguards. And best of all: mudguards are included with every PARALANE.

  • Greater comfort means less fatigue

    The Endurance geometry is designed for extended tours and the frame for maximum comfort, ensuring even longer cycling enjoyment.

Geometry

XS S M L XL XXL
A Size (MM) 450 480 510 530 550 590
B Effective Top Tube (MM) 498.5 527 547 562 578 592
C Head Tube Angle (°) 71 71.5 72 72 72.5 72.5
D Effective Seat Tube Angle (°) 75.5 74.5 73.5 73.5 73.5 73.5
E Chainstay (MM) 415 415 415 415 415 415
F BB Drop (MM) 75 75 75 75 75 75
G Head Tube Length (MM) 120 150 165 180 200 215
H Fork Length (MM) 383 383 383 383 383 383
I Fork Offset (MM) 46 46 46 46 46 46
J Wheelbase (MM) 975.5 991 996 1011 1022 1037
K Stack (MM) 536 566 582 596 617 632
L Reach (MM) 360 370 375 385 395 405

Specification

Frame
7005 hydroformed aluminum, disc, BSA BB, 142x12 mm through axle, RAT Evo technology, flat mount 140 mm, internal brake & gear cable routing
Fork
Carbon, disc, 100x12 mm RAT through axle, RAT Evo Technology, flat mount 140 mm, internal brake cable routing
Handlebar
BBB Basic, Aluminium, drop: 125 mm, reach: 70mm
Saddle
Velo VL-1489 Steel Rail
Seatpost
BBB Basic, Aluminium, 25,4mm, 350mm, set-back 20mm
Stem
BBB Basic, aluminium, 31.8mm, +/- 7 degree
Tire
Continental Contact Speed, 28-622
Brake levers
SRAM Apex
BrakeSystem
Sram Apex hydraulic disc, 160 / 160 mm
Brake type
Disc
Crankset
Sram S350, 44T
Rear derailleur
Sram Apex
Shifters
Sram Apex 1x
Sprocket
Sram PG-1130, 11-36T
Gear ratio
front: 44, rear: 11-36
Wheelset
Novatec N30, disc center-lock, aluminium, 100x12 / 142x12 mm, 20 mm inner rim width
