JARIFA² 3.9

Geometry Specification
SKU
FO5080014v2019

JARIFA² 3.9 Features

Ready for any adventure: high-performance Bosch Performance CX motor

Reliable Shimano brakes

Robust drive components from Shimano

Inspires you to get away

  • It's the ride characteristics that count

    The path to your ultimate goal should be full of laughter and fun. Which is why our JARIFA² is designed with mountain bike geometry and excellent off-road capability.

  • Prepared for anything

    The integrated lighting system from Supernova on your handlebar not only looks cool, it will get you safely through the dark.

  • The choice is yours

    You can choose from a range of different wheel sizes to best suit your individual requirements. Furthermore, the battery is removable on all models to enable easy charging in the comfort of your home.

Geometry

XS S M L XL
Frame size cm 40 42 46 50 54
A Size (MM) 400 420 460 500 540
B Effective Top Tube (MM) 563 573 583 604 619
C Head Tube Angle (°) 69 70 70 70 70
D Effective Seat Tube Angle (°) 73.5 74 74 74 74
E Chainstay (MM) 470 485 485 485 485
F BB Drop (MM) 48 62 62 62 62
G Head Tube Length (MM) 120 100 110 130 150
H Fork Length (MM) 487 501 501 501 501
I Fork Offset (MM) 44 44 44 44 44
J Wheelbase (MM) 1111 1126 1137 1158 1175
K Stack (MM) 602 615 404 643 662
L Reach (MM) 384 397 624 419 429

Specification

Frame
6061 aluminium, 148x12 mm through axle, internal cable routing, post mount 180 mm
Fork
SR Suntour XCM RL DS, 100 mm travel
Motor
Bosch Performance Line CX, 36 V / 250 W
Shifters
Shimano SL-M200
Rear derailleur
Shimano Deore 592, 9-speed
Sprocket description
Shimano HG400 9S, 12-36T
Chain description
KMC X9
Crankset description
FSA CK-310
Handlebar
Sport Riser, aluminium, risebar, 700mm, rise: 20mm
Grip/Tape description
Velo VLG-975
Stem
aluminium, 31.8mm
Saddle description
Focus Sport Saddle
Seatpost
Sport components SP-DC1, 31,6x350 mm
BrakeSystem
Shimano BR-MT200, 180 mm / 160 mm
Wheelset
Rodi Viper 21, 29" 622-21, Shimano TX-505 CL, 9 mm QR / 9 mm QR
Tire Description
Schwalbe Rapid Rob 2.25
Travel
100 mm
Display
Bosch Purion, LCD display with walk assist
Transmission of drive
front: 20, rear: 12-36
Brake type
Disc
Battery Watt-hours
400 Wh
Battery Ampere hours
11 Ah
Brake levers
Shimano MT200
