MARES 6.7

Geometry Specification
SKU
FO0080009v2019

MARES 6.7 Features

Robust and lightweight aluminium frame with full-carbon fork, R.A.T. floating axle and 100% FOCUS CX racing geometry

Reliable Shimano Tiagra gearshift

Robust and lightweight Shimano WH-RS170 wheelset

Defies adverse conditions

  • 25 years of setting the cyclocross benchmark

    Years of feedback from professional riders have made the MARES what it is today: THE cyclocross benchmark.

  • Frame protection ex works

    It's often very minor things that make all the difference between victory and defeat. Our proprietary-developed FOCUS CX chain guide prevents the chain from dropping.

  • The world's fastest floating axle

    Easier and faster: thanks to our patented FOCUS R.A.T. floating axle, wheel changes can be achieved in under 10 seconds.

Geometry

XS S M L XL XXL
A Size (MM) 480 510 540 560 580 600
B Effective Top Tube (MM) 518 529 538 550 558 570
C Head Tube Angle (°) 70 70 70.5 71 71 71.5
D Effective Seat Tube Angle (°) 73.5 73.5 73.5 73.5 73.5 73.5
E Chainstay (MM) 425 425 425 425 425 425
F BB Drop (MM) 65 65 65 65 65 65
G Head Tube Length (MM) 120 130 140 150 160 170
H Fork Length (MM) 400 400 400 400 400 400
I Fork Offset (MM) 45 45 45 45 45 45
J Wheelbase (MM) 999 1010 1015 1023 1031 1038
K Stack (MM) 539 549 560 571 581 592
L Reach (MM) 358 367 372 381 386 395

Specification

Frame
7005 aluminum, disc, BSA BB, 142x12 mm through axle, RAT Evo technology, flat mount 140 mm, internal brake & gear cable routing
Fork
Carbon, disc, 100x12 mm RAT through axle, RAT Evo Technology, flat mount 140 mm, internal brake cable routing
Handlebar
BBB Basic, Aluminium, drop: 125 mm, reach: 70mm
Saddle
Prologo Scratch
Seatpost
BBB Basic, Aluminium, 27,2mm, 350mm, set-back 20mm
Stem
BBB Basic, aluminium, 31.8mm, +/- 7 degree
Tire
Continental Race King CX, 700 x 35C
Brake levers
Shimano Tiagra
BrakeSystem
Shimano RS405 hydraulic disc, 160 / 160 mm
Brake type
Disc
Crankset
Shimano Tiagra 4700, 50/34T
Rear derailleur
Shimano Tiagra R4700
Shifters
Shimano Tiagra
Sprocket
Shimano HG500, 11-34T
Gear ratio
front: 50/34, rear: 11-34
Wheelset
Shimano WH-RS170, disc center-lock, aluminium, 100x12/142x12 mm, 28/28 spokes, 17 mm inner rim width
