IZALCO RACE DISC 9.9

Geometry Specification
SKU
FO0030010v2019

IZALCO RACE DISC 9.9 Features

Lightweight carbon frame with integrated cable routing, disc brakes and R.A.T. floating axles

Long service life and reliable gear shifting: Shimano 105

Robust and lightweight Shimano WH-RS170 wheelset

Shines on the road

  • No loss of power

    Our IZALCO RACE is there when you need it. Thanks to its high rigidity, no power is lost, your calf power is converted directly into forward motion.

  • The world’s fastest quick-release axle

    Quicker and simpler: Thanks to our patented FOCUS R.A.T.* quick-release axle, wheel changes can be carried out in under ten seconds.

  • No cables to spoil the visual appearance

    Ideal protection and visually appealing: thanks to its integrated cable routing, it is not possible for dirt to restrict the functioning of the IZALCO RACE.

Geometry

XS S M L XL
Size 48 51 54 57 60
Seat post length XS S M L XL
Handlebar width 400 400 420 420 440
Stem Length (MM) 90 100 100 110 120
Crankarm length 170 170 172,5 172,5 175
A Size (MM) 480 510 540 570 600
B Effective Top Tube (MM) 503 537 552 569 589
C Head Tube Angle (°) 71 72 72.5 73.5 73.5
D Effective Seat Tube Angle (°) 75.5 73.5 73.5 73.5 73.5
E Chainstay (MM) 415 415 415 415 415
F BB Drop (MM) 70 70 70 70 70
G Head Tube Length (MM) 115 130 145 165 185
H Fork Length (MM) 370 370 370 370 370
I Fork Offset (MM) 43 43 43 43 43
J Wheelbase (MM) 978 984 995 1002 1022
K Stack (MM) 513 531 547 569 589
L Reach (MM) 370 380 390 400 415

Specification

Frame material
carbon
Frame
Carbon SL, disc, Pressfit 86 BB, 142x12 mm thru axle, R.A.T Evo technology, Di2 ready, flat mount 140 mm, internal brake & gear cable routing
Fork
IZALCO RACE Carbon, disc, 12 x 100 mm R.A.T. thru axle, flat mount 140 mm, internal brake cable routing
Shifter
Shimano 105 R7025
Front derailleur
Shimano 105 R7000
Rear derailleur
Shimano 105 R7000
Sprocket
Shimano 105 R7000
Chain
Shimano CN-HG601
Crankset
Shimano 105 R7000, 50/34T
Transmission of drive
front: 50/34, rear: 11-30
Bottom Bracket
Shimano Pressfit Road BB86
Handlebar
BBB Basic, aluminium, drop: 125 mm, reach: 70mm
Grips
FOCUS Bartape SL
Stem
BBB Basic, aluminium, 31.8mm, +/- 7 degree
Headset
1-1/8", tapered, IS 47/33
Saddle
Prologo Kappa RS STN Rail
Seatpost
BBB CPX Plus, Carbon, 27,2mm, 350mm, set-back: 20mm
Brakes
Shimano 105 R7025 hydraulic disc
Brake lever description
-
Brake
Disc
Wheelset
Shimano WH-RS170, disc center-lock, aluminium, 100x12/142x12 mm, 28/28 spokes, 17 mm inner rim width
Tires
Continental Ultra Sport II, 700 x 25C, Folding
Gears
22
Size
48,57,51,54,60
* Subject to technical modification without notice. Errors and omissions excepted. ** Weight in size M, of standard specification and without pedals.
