Exemplary bike presentation. Actual parts are shown in the specifications list.
Provides support at just the right moment
-
Combines the advantages of a racing bike with those of an e-bike
Light and agile, but with an extra push from the Fazua Evation drive with its 252 Wh battery capacity when you need a little extra support: the removable motor/battery unit is uncoupled from the drive and only noticeable when it is making your ride easier.
-
Greater tyre clearance for more freedom
The maximum tyre clearance of up to 35 mm makes it possible for you to ride on all paths, regardless of whether they are asphalt roads or gravel tracks.
-
Optimal shifting function
Thanks to our revolutionary Road Boost Standard with its broad 148 and 110 mm R.A.T.* Our axles guarantee an optimal chain line for racing e-bikes and therefore an optimal shifting function and less wear.
Geometry
S | M | L | XL | ||
---|---|---|---|---|---|
Size | 51 | 54 | 57 | 60 | |
Size (MM) | 480 | 516 | 540 | 570 | |
Handlebar width | 400 | 420 | 420 | 440 | |
Stem Length (MM) | 90 | 100 | 110 | 120 | |
Crankarm length | 170 | 172,5 | 172,5 | 175 | |
A | Seat tube length (MM) | 480 | 516 | 540 | 570 |
B | Effective Top Tube (MM) | 525 | 545 | 568 | 590 |
C | Head Tube Angle (°) | 71.5 | 72 | 72.5 | 72.5 |
D | Effective Seat Tube Angle (°) | 74.5 | 73.5 | 73.5 | 73.5 |
E | Chainstay length (MM) | 415 | 415 | 415 | 415 |
F | Bottom bracket drop (MM) | 75 | 75 | 75 | 75 |
G | Head Tube Length (MM) | 150 | 165 | 190 | 215 |
H | Fork construction height (MM) | 380 | 380 | 380 | 380 |
I | Pre-raked fork (MM) | 46 | 46 | 46 | 46 |
J | Wheelbase length (MM) | 990 | 996 | 1014 | 1036 |
K | Stack (MM) | 564 | 580 | 605 | 630 |
L | Reach (MM) | 370 | 375 | 390 | 405 |

Specification
Frame
F.I.T carbon E-Road, disc, road boost 148x12 mm thru axle, R.A.T Evo technology, flat mount 160 mm, internal cable routing
Frame material
Carbon
Fork
Carbon, disc, road boost 110x12 mm, thru axle, R.A.T Evo technology, flat mount 160/140 mm, internal cable routing
Motor
FAZUA evation, 60 Nm, 250 W
Battery Watt-hours
250 Wh
Battery Ampere hours
7 Ah
Display
FAZUA evation 1.0 remote
Shifter
Shimano Dura Ace R9170, Di2
Front derailleur
Shimano Dura-Ace R9150, Di2
Rear derailleur
Shimano Dura-Ace R9150 Di2
Sprocket
Shimano Dura-Ace R9100
Chain
Shimano CN-HG901
Crankset
FSA, carbon
Transmission of drive
front: 52/36, rear: 11-30
Bottom Bracket
-
Handlebar
Easton EC90 Aero, carbon, drop: 125mm, reach: 80mm
Grips
FOCUS Bartape SL
Stem
BBB Deluxe, aluminium, 31.8mm, +/- 7 degree
Headset
IS42/28.6 - IS52/40
Saddle
Prologo Scratch
Seatpost
BBB CPX Plus, Carbon, 27,2mm, 350mm, set-back: 20mm
Brakes
Shimano Dura Ace R9170 hydraulic disc
Brake lever
Shimano Dura Ace R9170, Di2
Brake
Disc
Wheelset
DT Swiss ERC 1450 DB, 47mm height, road boost
Tires
Vittoria Corsa Control, 700 x 28C, Folding
Fender
Curana C-Lite
Gears
22
Bike weight incl. battery in kg.
12,80 kg
Size
51,54,57,60
* Subject to technical modification without notice. Errors and omissions excepted.
** Weight in size M, of standard specification and without pedals.
