JARIFA² 6.8

Geometry Specification
SKU
FO5080087v2022

Escape the daily grind

  • Super powerful and dynamic e-motor

    The efficient Bosch Performance CX e-drive (Gen. 4) supports your ride up to 25 km/h with powerful 85 Nm. A well-balanced geometry makes the JARIFA² ride agile and dynamic. The strongest e-motor of Bosch is perfectly integrated into the bottom bracket area.

  • Record-breaking integrated range and a new display

    The new Bosch Powertube battery (smart system) with its record-breaking 750 Wh (size XS and S: 625 Wh) is perfectly integrated into the down tube, yet it can also be removed at any time for charging. Furthermore, the latest Kiox 300 offers a bigger, easier-to-read display with a new remote and better ergonomics. Additionally, a USB-C port on the top tube gives you the opportunity to charge your devices.

  • Extra-comfortable, integrated and easy to retrofit

    The JARIFA² combines MTB and trekking DNA. The cockpit with a 30-degree stem and ergonomic parts make your ride comfortable even on rides off the beaten track. The C.I.S. (Cockpit Integration Solution) technology offers a clean cockpit with cable routing through stem and headset into the frame. Additionally, the JARIFA² can be retrofitted easily thanks to respective mounting points. On top, the JARIFA² 6.8 is approved for most trailers and for a system weight (rider plus gear and bike) of 150 kg. Considering the needs of smaller riders, the JARIFA² models in size XS roll on 27,5" wheels.

Geometry

XS S M L XL
Size 36 40 44 48 52
Size (MM) 360 400 440 480 520
Handlebar width 760 760 760 760 760
Stem Length (MM) 60 60 60 60 60
Crankarm length 170 170 170 170 170
Seat post length (MM) 350 350 350 350 350
A Seat tube length (MM) 360 400 440 480 520
B Effective Top Tube (MM) 561 594 615 638 662
C Head Tube Angle (°) 67 67 68 68 68
D Effective Seat Tube Angle (°) 74 74 74 74 74
E Chainstay length (MM) 460 470 470 470 470
F Bottom bracket drop (MM) 45 65 65 65 65
G Head Tube Length (MM) 120 130 130 140 160
H Fork construction height (MM) 495 515 515 515 515
I Pre-raked fork (MM) 51 51 51 51 51
J Wheelbase length (MM) 1102 1175 1180 1209 1211
K Stack (MM) 597 642 644 653 672
L Reach (MM) 390 410 430 450 470

Specification

Frame
7005 hydroformed aluminium, 3D forging, 148x12 mm thru axle, USB-C port, post mount 180 mm
Frame material
Aluminium
Fork
SR Suntour XCR 34 LO Air, 15x110 mm
Travel Fork
100 mm
Motor
Bosch Performance CX Smart, 85 Nm, 250 W
Battery Watt-hours
625 Wh,750 Wh
Battery Ampere hours
17,4 Ah,20,8 Ah
Display
Bosch LED Remote + Kiox 300
Shifter
Shimano Deore M5100, 11-speed
Rear derailleur
Shimano Deore RD-M5100, 11-speed
Sprocket
Shimano Deore CS-M5100, 11-speed
Chain
Shimano CN-HG601, 11-speed
Crankset
FSA CK-320, aluminium
Bottom Bracket
Integrated in Drive Unit
Transmission of drive
front: 36, rear: 11-51
Handlebar
Aluminium, 760 mm, flatbar, backsweep: 9°, 35,0 mm
Stem
FOCUS C.I.S. integrated, 60 mm, 30°, 35 mm, aluminium
Headset
ACROS ZS56/ZS66 (ICR), FOCUS C.I.S. Integrated
Saddle
Selle Royal Vivo
Seatpost
Aluminium, 31.6 mm
Brakes
Shimano MT410, 2-piston, hydraulic disc brake
Brake lever
Shimano MT410
Brake
Disc
Rims
RODI TRYP25, 25-622
Rear hub
Shimano Alivio MT400, 12x148 mm
Front Hub
Shimano Alivio MT400, 15x110 mm
Tires
Schwalbe Smart Sam 2.25, 57-622,Schwalbe Smart Sam, 57-584
Gears
11
Bike weight incl. battery in kg.
*,24,2 kg
Size
40,36,48,44,52
Shifting type
Mechanical shifting
* Subject to technical modification without notice. Errors and omissions excepted. ** Weight in size M, of standard specification and without pedals.
