FOCUS O1E 9.9

Geometry Specification
SKU
FO3150001v2019

FOCUS O1E 9.9 Features

Super-lightweight MAX carbon frameset (complete frame only 1830 g) with R.A.T. Quick-release axle

Race-oriented 100 mm F.O.L.D. Chassis: Fox Float Step-Cast Factory suspension fork and Fox Float DPS damper

Ultimate precision: Shimano XTR 1x12 shifter components and Shimano XTR brakes

Shifts racing requirements

  • Loved by professionals

    XC world-class athletes oversaw the development of the FOCUS O1E – ensuring that the highest demands were met.

  • Optimum suspension performance for every situation

    The F.O.L.D. kinematics specially tailored to the demands of cross-country helps you push the boundaries and reach the finish line faster.

  • Sets the benchmark in lightweight construction

    The extremely lightweight frame and kinematics make every uphill climb a breeze.

Geometry

S M L
Frame size cm 42 45 48
A Size (MM) 422 445.8 482.2
B Effective Top Tube (MM) 584 602 623
C Head Tube Angle (°) 69.2 69.2 69.2
D Effective Seat Tube Angle (°) 74.5 74.5 74.5
E Chainstay (MM) 448 448 448
F BB Drop (MM) 38 38 38
G Head Tube Length (MM) 100 112 125
H Fork Length (MM) 511 511 511
I Fork Offset (MM) 46 46 46
J Wheelbase (MM) 1127 1146 1167
K Stack (MM) 598 605 622
L Reach (MM) 419 435 450

Specification

Frame
MAX technology Carbon frame, 100 mm F.O.L.D. kinematic, PF30 BB, 148x12 mm through axle, internal cable routing, Post Mount 160 mm
Fork
Fox 32 Float SC Factory, 2-position remote w/ open mode, 15 x 110 mm QR, 100 mm travel
Rear shock
Fox Float DPS Factory, 2-position lockout, EVOL, 165/38 mm, hardware: 22,2 x 8mm, custom tune
Shifters
Shimano XTR 9100, 12-speed
Rear derailleur
Shimano XTR 9100, 12-speed
Sprocket description
Shimano XTR 9100. 12-speed, 10-51T
Chain description
Shimano XTR CN-M9100
Crankset description
RaceFace Next SL G5, carbon
Handlebar
BBB, carbon, flatbar, 720mm, rise: 0mm, backsweep: 9degree
Grip/Tape description
Velo VLG-975
Stem
BBB Race, aluminium, 31.8 mm
Saddle description
Prologo Scratch X8, 7x9mm carbon rail
Seatpost
BBB, carbon, 31,6mm
BrakeSystem
Shimano XTR M9100
Wheelset
DT Swiss XRC1200, carbon, 622-25
Tire Description
Schwalbe Racing Ralph Evo Addix Speed 2.25
Bike weight incl. battery in kg.
10,80 kg
Brake levers
Shimano XTR M9100
Transmission of drive
front: 32, rear:10-51
Travel
100 mm
Brake type
Disc
