WHISTLER 3.5

Geometry Specification
SKU
FO3040013v2019

WHISTLER 3.5 Features

Lightweight aluminium frame with 29" or 27" wheels, depending on size

Comfort and control: SR Suntour XCT suspension fork with 100 mm suspension travel

Robust drive components from Shimano

Sport comes naturally

  • The choice is yours

    With the WHISTLER, you can choose between 27.5" and 29" wheelsets. Opt for the wheelset size that best suits your height and your requirements.

  • Prepared for anything

    Mounting options for pannier rack, mudguard, light and stand allow you to tailor the bike to your own individual requirements.

  • Consistent brake performance

    You need a reliable partner to handle hairy situations. That's why we've equipped our WHISTLER model with disc brakes – for a consistent braking performance and optimum braking behaviour.

Geometry

XS S M L XL
Frame size cm 36 40 44 48 52
A Size (MM) 360 400 440 480 520
B Effective Top Tube (MM) 554 575 588 608 624
C Head Tube Angle (°) 69 70 70 70 70
D Effective Seat Tube Angle (°) 73.5 74 74 74 74
E Chainstay (MM) 448 464 454 454 454
F BB Drop (MM) 48 62 62 62 62
G Head Tube Length (MM) 120 110 120 140 160
H Fork Length (MM) 489 509 509 509 509
I Fork Offset (MM) 42 51 51 51 51
J Wheelbase (MM) 1079 1192 1119 1141 1158
K Stack (MM) 604 629 638 657 676
L Reach (MM) 375 395 405 420 430

Specification

Frame
6061 aluminium, BSA BB, international disc brake standard
Fork
SR Suntour XCT 30 DS, 100 mm travel
Handlebar
Sport Riser, aluminium, risebar, 700mm, rise: 20mm
Saddle description
Focus Sport Saddle
Seatpost
aluminium, 27,2mm
Stem
aluminium, 31.8mm
Tire Description
Impac Ridgepac 2.1
Brake levers
Shimano EF505
BrakeSystem
Shimano BR-MT200, 160 mm / 160mm
Brake type
Disc
Crankset description
Shimano FC-TY301, SQ, 42/34/24T
Rear derailleur
Shimano TX800, 8-speed
Shifters
Shimano ST-EF505
Sprocket description
Shimano HG-200, 12-32T
Transmission of drive
front: 42/34/24 rear: 11-32
Travel
100 mm
Wheelset
Rodi Viper 21, 27" 584-21, 29" 622-21, Shimano TX-505 CL, 9 mm QR / 9 mm QR
Chain description
KMC X8.93
Grip/Tape description
Focus SL
