Geometry Specification

FOCUS SAM² 6.7 Features

Powerful and perfectly tuned: Shimano E8000 drive with smart 756 Wh battery power

170 mm F.O.L.D. Chassis: Solid RockShox Yari suspension fork and RockShox Deluxe Select damper

Simple Sram NX1 Eagle shifter and powerful Magura MT5 brakes

Rediscover Enduro

  • Always as much energy as you need

    The new and easy-to-install TEC pack puts up to 756 Wh at your disposal for those longer tours. Pack your equipment on the smart rack and store your bottle on the down tube. You can tailor your bike to your own requirements.

  • Optimum suspension performance for every situation

    Our F.O.L.D. chassis is specially designed to meet the very high demands of an E-MTB. So we can guarantee that our E-Enduro FOCUS SAM² is also the perfect combination: F.O.L.D. is extremely sensitive while being progressive enough to prevent a harsh bottom out.

  • It's the ride characteristics that count

    Thanks to the compact design of the Shimano E8000 motor and our battery, we were able to create a modern, agile and aggressive geometry for the FOCUS SAM². This ensures that you have just as much fun on the trail as with our FOCUS SAM without assistance.


Frame size cm 42 44 48
A Size (MM) 420 440 480
B Effective Top Tube (MM) 585 604 624
C Head Tube Angle (°) 65 65 65
D Effective Seat Tube Angle (°) 75 75 75
E Chainstay (MM) 455 455 455
F BB Drop (MM) 12 12 12
G Head Tube Length (MM) 118 118 138
H Fork Length (MM) 562 562 562
I Fork Offset (MM) 42 42 42
J Wheelbase (MM) 1196 1217 1240
K Stack (MM) 607 607 625
L Reach (MM) 425 440 455


7005 hydroformed aluminium, 3D forging, 170 mm F.O.L.D. kinematic, 148x12 mm through axle, internal cable routing, post mount 180 mm
RockShox Yari RC, 15x110 mm
Rear shock
RockShox Deluxe Select, 230/65 mm, hardware: 25,0 x 8mm, custom tune
Shimano Steps E8000, 70 Nm, 250 W
Sram NX Eagle, 12-speed
Rear derailleur
Sram NX Eagle, 12-speed
Chain description
Sram NX Eagle
Crankset description
Shimano FC-E8000
BBB Ascension BHB-110-Di2, aluminium, riserbar, 780mm, rise: 20mm, backsweep: 9degree
Grip/Tape description
Focus Locker SL
Aluminium, 40mm
Saddle description
Focus Trail SL
Kindshock E30i, 31,6mm
Magura MT5, 4 piston
Tire Description
Maxxis Assegai 2.5 3C MaxxTerra Exo+ TR
Bike weight incl. battery in kg.
24,7 kg
Brake type
Brake levers
Magura MT5
Battery Watt-hours
378 Wh
170 mm
Battery Ampere hours
10,5 Ah
Shimano Steps E7000, black/white LCD display, walk assist, bluetooth
