AVENTURA² 6.9

Geometry Specification
SKU
FO5080083v2023

AVENTURA² 6.9 Features

Bosch CX e-drive & 750 (size S: 625) Wh battery

SR Suntour Raidon LOR fork, 4-piston brakes and 130 Lux light

Comfortable C.I.S. cockpit & Shimano XT 12-speed

Awakens your inner explorer

  • Super powerful and dynamic e-motor

    The efficient Bosch Performance CX e-drive (Gen. 4) supports your ride up to 25 km/h with powerful 85 Nm. A well-balanced geometry makes the AVENTURA² ride agile and dynamic. The strongest e-motor of Bosch is perfectly integrated into the bottom bracket area.

  • Integrated battery with record-breaking range and a new display

    The new Bosch Powertube battery (smart system) with its record-breaking 750 Wh (size S: 625 Wh) is perfectly integrated into the down tube, yet it can also be removed at any time for charging. Furthermore, the latest Kiox 300 offers a bigger, easier-to-read display with a new remote and better ergonomics. Additionally, a USB-C port on the top tube gives you the opportunity to charge your devices.

  • Ready for anything

    Regardless of whether your journey lasts several days or you simply need to transport a lot of belongings: with its pannier rack, fenders, kickstand, lock mount and light, the AVENTURA² is equally well-prepared for bikepacking trips and transporting heavy loads across the city. You can choose between a wave or a diamond frame: Easy to step in and out or more sportive – we have the frame shape you prefer. On top, the AVENTURA² 6.9 is approved for most trailers and for a system weight (rider plus gear and bike) of 150 kg. The ergonomic cockpit with a 30-degree stem and wide off-road tyres make your ride comfortable even off the beaten track. The C.I.S. (Cockpit Integration Solution) technology offers a clean cockpit with cable routing through stem and headset into the frame.

Geometry

S M L XL
Size (MM) 40 44 48 52
Size 400 440 480 520
Handlebar width (MM) 760 760 760 760
Stem Length 60 60 60 60
Crankarm length (MM) 170 170 170 170
Seat post length 350 350 350 350
A Seat tube length 400 440 480 520
B Effective Top Tube 593 613 634 660
C Head Tube Angle (MM) 68 68 68 68
D Effective Seat Tube Angle (MM) 73.5 73.5 73.5 73.5
E Chainstay length 470 470 470 470
F Bottom bracket drop 65 65 65 65
G Head Tube Length 135 135 140 160
H Fork construction height 515 515 515 515
I Pre-raked fork 51 51 51 51
J Wheelbase length 1152 1172 1191 1217
K Stack 650 650 656 675
L Reach 400 420 440 460

Specification

Frame
7005 hydroformed aluminium, 3D forging, 148x12 mm thru axle, USB-C port, internal cable routing, post mount 180 mm,7005 hydroformed aluminium, 3D forging, 148x12 mm thru axle, USB-C port, post mount 180 mm
Fork
SR Suntour Raidon 34 LOR AIR, 110x15 mm
Travel of suspension fork
100 mm
Motor
Bosch Performance Line CX Smart System, 36 V / 250 W / 85 Nm
Battery Watt-hours
625 Wh,750 Wh
Battery Ampere hours
17,4 Ah,20,8 Ah
Display
Bosch LED Remote + Kiox 300
Shifter
Shimano Deore M6100, 12-speed
Rear derailleur
Shimano Deore XT M8100, 12-speed
Sprocket
Shimano Deore CS-M6100, 12-speed
Chain
Shimano Deore CN-M6100, 12-speed
Crankset
FSA CK-320, aluminium
Transmission of drive
front: 36, rear: 10-51
Bottom Bracket
Integrated in Drive Unit
Handlebar
Aluminium, 760 mm, flatbar, backsweep: 9°, 35,0 mm
Stem
FOCUS C.I.S. integrated, 60 mm, 30°, 35 mm, aluminium
Headset
ACROS ZS56/ZS66 (ICR), FOCUS C.I.S. Integrated
Saddle
Selle Royal Vivo
Seatpost
Aluminium, 31.6 mm
Brake caliper
Shimano MT420, 4-piston, hydraulic disc brake
Brake lever
Shimano BR-MT420
Brake
Disc
Wheelset
Shimano WH-MT501, 24-622, 15x110 mm / 12x148 mm
Tires
Schwalbe Smart Sam 2.25, 57-622
Fender
Büchel, aluminium, 60 mm, powder-coated
Headlight
Litemove AE130, high-beam, 130 LUX
Taillight
Herrmans H-Trace Mini
Gears
12
Bike weight incl. battery in kg.
*,26,60 kg
Size
40,44,48,52
* Subject to technical modification without notice. Errors and omissions excepted. ** Weight in size M, of standard specification and without pedals.
