JAM 6.9

Geometry Specification
SKU
FO3120007v2021

JAM 6.9 Features

Aluminium frame with tool bag

150 mm FOX 36 Performance fork & DPS shock

Shimano XT 1x12

Makes the mountains your playground

  • Optimized kinematics for strong progression

    With the upgrade of our well-known F.O.L.D. kinematics, your JAM is ready to shred even more. We kept the well-liked sensitivity of the F.O.L.D. but changed the positioning of our kinematics within the frame for strong bottom-out resistance. The characteristics are completely progressive which results in a chassis that offers a lot of stability in rough terrain. This allows you to handle any trail while the chassis still provides comfort for long laps. Furthermore, the lower standover of the JAM gives you more space to play on the trail.

  • For your inner child

    The JAM is made for your inner child: Playful and intuitive you get the most fun out of every ride. The geometry is well-balanced for your rides in tough terrain: An agile handling merges with a lot of safety resources of the chassis providing confidence in rough downhills. You are perfectly-seated in the middle of the bike to be in control of any situation and to easily pedal up all the steep hills on your ride. The FLIP CHIP at your linkage can be used to adjust your geometry to an even more aggressive riding style. The small adjustment of the head angle from 65,5° to 65° changes your set-up making it even more downhill-oriented.

  • Integrated and clean

    It's all about details: The specially developed C.I.S. (Cockpit Integration Solution) design ensures a clean cockpit and constantly seamless shifting and braking. All cables run from the handlebar into the stem and through the headset into the frame. Furthermore, the JAM 6.9 comes with a tool bag between the top and down tube angle. The tool bag offers space for all your essentials like a multi-tool, tube and a small pump.

Geometry

S M L XL
Size (MM) 39 42 45 47
Size 390 420 450 470
Handlebar width (MM) 780 780 780 780
Stem Length 50 50 50 50
Crankarm length (MM) 170 170 170 170
Seat post length 125 150 170 170
A Seat tube length 390 420 450 470
B Effective Top Tube 570 603 637 672
C Head Tube Angle (MM) 65 65 65 65
D Effective Seat Tube Angle (MM) 76 76 76 76
E Chainstay length 435 435 435 435
F Bottom bracket drop 30 30 30 30
G Head Tube Length 90 100 120 140
H Fork construction height 561 561 561 561
I Pre-raked fork 44 44 44 44
J Wheelbase length 1166 1200 1238 1277
K Stack 603 612 630 648
L Reach 420 450 480 510
S M L XL
Size (MM) 39 42 45 47
Size 390 420 450 470
Handlebar width (MM) 780 780 780 780
Stem Length 50 50 50 50
Crankarm length (MM) 170 170 170 170
Seat post length 125 150 170 170
A Seat tube length 390 420 450 470
B Effective Top Tube 570 603 637 672
C Head Tube Angle (MM) 65.5 65.5 65.5 65.5
D Effective Seat Tube Angle (MM) 76.5 76.5 76.5 76.5
E Chainstay length 435 435 435 435
F Bottom bracket drop 24 24 24 24
G Head Tube Length 90 100 120 140
H Fork construction height 561 561 561 561
I Pre-raked fork 44 44 44 44
J Wheelbase length 1166 1200 1238 1277
K Stack 603 612 630 648
L Reach 425 455 485 515

Specification

Frame material
Aluminium
Frame
7005 hydroformed aluminium, 3D forging, 150 mm F.O.L.D. Gen2 kinematics, 148x12 mm thru axle, internal cable routing, post mount 180 mm
Fork
FOX 36 Float Performance 29, Grip 3-Position, 110x15 mm, 44 mm rake
Travel of suspension fork
150 mm
Shock
FOX Float DPS Performance, 3-position lever, 210/55 mm, hardware: 25,0 x 8mm, custom tune
Shifter
Shimano Deore XT M8100, 12-speed
Rear derailleur
Shimano Deore XT M8100, 12-speed
Sprocket
Shimano Deore M6100, 12-speed
Chain
Shimano Deore CN-M6100, 12-speed
Crankset
Shimano Deore XT FC-M8100, Hollowtech II
Transmission of drive
front: 32, rear: 11-51
Bottom Bracket
BSA
Handlebar
RaceFace Chester 35, aluminium, 780 mm, rise: 35 mm, backsweep: 8°
Stem
FOCUS C.I.S. integrated, 50 mm, 0°, 35 mm, aluminium
Headset
ACROS ZS56/ZS56 (ICR), FOCUS C.I.S. Integrated
Saddle
fi'zi:k Taiga
Seatpost
Post Moderne dropper post PM-171, 31.6 mm
Brake caliper
Shimano XT M8120, 4 piston
Brake lever
Shimano XT M8120, 4 piston
Brake
Disc
Wheelset
DT Swiss M1900, 622-30, 148x12 mm / 110x15 mm
Rear hub
Novatec D462SB, 12x148 mm
Front Hub
Novatec D041, 15x110 mm
Tires
Maxxis Minion DHF, 2.5 WT 3C EXO TR, 63-622
Rear tire
Maxxis Minion DHR II, 2.4 3C EXO+, 61-622
Gears
12
Bike weight incl. battery in kg.
15,9 kg
Size
39,42,45,47
* Subject to technical modification without notice. Errors and omissions excepted. ** Weight in size M, of standard specification and without pedals.
