IZALCO MAX DISC 9.7 Features
Super-lightweight MAX aero carbon frame (890 g frame only) including aero carbon stem and R.A.T.* Quick-release axles
Precise electronic shifting: Shimano Ultegra Di2
Super-fast DT Swiss ARC1450 DICUT carbon wheelset with rim height of 48 mm
More than just the fastest
-
Optimised in the wind tunnel
The balanced proportions of the frame, which incorporates MAX Carbon Technology and elegant tubes with Kammtail profiles, provide the ultimate combination of aerodynamics and low weight. When combined with integrated cables and our aero stem and aero seat posts, we offer as little wind resistance as possible.
-
To sum up, it is simply faster
Go faster for longer thanks to increased comfort: The 15 mm offset of the aerodynamic carbon seat post provides perfect ergonomics and comfort. However, since the seat tube of the IZALCO MAX has been offset in the forward direction, the effective offset is just 2 mm. As a result, you can enjoy complete comfort while at the same time riding in a modern racing sitting position.
-
More than just the fastest
The IZALCO MAX is a statement. It provides more than just aerodynamics, low weight and incredible speeds. It combines all its skills to create a thrilling riding experience that will compel you to go out on more rides with your pals. Get more out of it together. With more style, elegance and dedication.
Geometry
| XXS | XS | S | M | L | XL | XXL | ||
|---|---|---|---|---|---|---|---|---|
| Size | 47 | 50 | 52 | 54 | 56 | 58 | 61 | |
| A | Size (MM) | 430 | 470 | 490 | 510 | 530 | 550 | 590 |
| B | Effective Top Tube (MM) | 504 | 517 | 535 | 551 | 564 | 582 | 602 |
| C | Head Tube Angle (°) | 69.5 | 70.5 | 71.5 | 72 | 72 | 72.5 | 72.5 |
| D | Effective Seat Tube Angle (°) | 74 | 73.5 | 73.5 | 73.5 | 73.5 | 73.5 | 73.5 |
| E | Chainstay (MM) | 410 | 410 | 410 | 410 | 410 | 410 | 410 |
| F | BB Drop (MM) | 78 | 78 | 78 | 78 | 78 | 78 | 78 |
| G | Head Tube Length (MM) | 80 | 80 | 100 | 115 | 125 | 150 | 185 |
| H | Fork Length (MM) | 392 | 392 | 392 | 392 | 392 | 392 | 392 |
| I | Fork Offset (MM) | 46 | 46 | 46 | 46 | 46 | 46 | 46 |
| J | Wheelbase (MM) | 975 | 975 | 985 | 997 | 1010 | 1024 | 1044 |
| K | Stack (MM) | 502 | 506 | 528 | 544 | 554 | 579 | 613 |
| L | Reach (MM) | 360 | 368 | 378 | 390 | 400 | 410 | 420 |
Specification
Frame
MAX technology carbon, disc, BB86, 142x12 mm through axle, RAT Evo technology, electronical shifting only, flat mount 160 mm, internal cable routing
Fork
MAX technology carbon, integrated, disc, 100x12 mm RAT through axle, RAT Evo Technology, flat mount 160/140 mm, internal brake cable routing
Shifter
Shimano Ultegra R8070, Di2
Front derailleur
Shimano Ultegra R8050, Di2
Rear derailleur
Shimano Ultegra R8050, Di2
Sprocket description
Shimano Ultegra R8000, 11-30T
Chain
Shimano CN-HG701
Crankset
Shimano Ultegra R8000, 52/36T
Handlebar
Easton EC90 Aero, carbon, drop: 125mm, reach: 80mm
Grips
Focus Bartape SL
Stem
Izalco Max carbon, integrated cable routing, 31.8mm, -15 degree
Saddle
Prologo Dimension
Seatpost
Izalco Max aero carbon, D-shape, 350 mm, set-back: 15mm
Brakes
Shimano Ultegra R8070 hydraulic disc
Wheelset
DT Swiss ARC 1450 DICUT DB, 48mm height
Tires
Vittoria Corsa, 700 x 25C, Folding
Bike weight incl. battery in kg.
7,60 kg
Headset
Acros, IS 52/40-IS52/42
Bottom Bracket
Shimano Pressfit Road BB86
Gears
22
Transmission of drive
front: 52/36, rear: 11-30
Brake levers
Shimano Ultegra R8070, Di2
Brake
Disc
* Subject to technical modification without notice. Errors and omissions excepted.
** Weight in size M, of standard specification and without pedals.
