Encourages you to escape from your everyday life
-
Super powerful and dynamic e-motor
The efficient Bosch Performance CX e-drive (Gen. 4) supports your ride up to 25 km/h with powerful 85 Nm. A well-balanced geometry makes the JARIFA² ride agile and dynamic. The 500 Wh battery can be removed for charging. The strongest e-motor of Bosch is perfectly integrated into the bottom bracket area.
-
Extra-comfortable and easy to retrofit
The JARIFA² combines MTB and trekking DNA. The cockpit with a 35-degree stem and ergonomic parts make your ride comfortable even on rides off the beaten track. Additionally, the JARIFA² can be retrofitted easily thanks to respective mounting points.
-
Especially for smaller riders
Considering the needs of smaller riders, the JARIFA² SEVEN models in size S and XS roll on 27,5" wheels. That matching combination of smaller frame and wheels makes sure the JARIFA² also rides perfectly in a smaller size.
Geometry
| XS | S | ||
|---|---|---|---|
| Size | 36 | 40 | |
| Size (MM) | 360 | 400 | |
| Handlebar width | 720 | 720 | |
| Stem Length (MM) | 70 | 70 | |
| Crankarm length | 170 | 170 | |
| A | Seat tube length (MM) | 350 | 350 |
| B | Effective Top Tube (MM) | 556 | 573 |
| C | Head Tube Angle (°) | 68 | 68 |
| D | Effective Seat Tube Angle (°) | 73.5 | 73.5 |
| E | Chainstay length (MM) | 460 | 460 |
| F | Bottom bracket drop (MM) | 48 | 48 |
| G | Head Tube Length (MM) | 115 | 120 |
| H | Fork construction height (MM) | 495 | 495 |
| I | Pre-raked fork (MM) | 42 | 42 |
| J | Wheelbase length (MM) | 1106 | 1123 |
| K | Stack (MM) | 601 | 605 |
| L | Reach (MM) | 380 | 395 |
Specification
Frame
7005 aluminium, 148x12 mm thru axle, internal cable routing, post mount 180 mm
Frame material
Aluminium
Fork
SR Suntour XCM 34 Air, 15x110 mm
Travel Fork
100 mm
Motor
Bosch Performance CX Gen4, 85 Nm, 250 W
Battery Watt-hours
500 Wh
Battery Ampere hours
13,4 Ah
Display
Bosch Purion
Shifter
Shimano Altus M2010, 9-speed
Rear derailleur
Shimano Altus M2000, 9-speed
Sprocket
Shimano HG400
Chain
Shimano HG53
Crankset
FSA CK-320, aluminium
Transmission of drive
front: 34, rear: 12-36
Bottom Bracket
Integrated in Drive Unit
Handlebar
Riser, Aluminium, 720mm
Grips
Herrmans Click
Stem
Aluminium, 70mm, 35degree
Headset
VP Components, ZS56/28,6-ZS56/40
Saddle
Selle Royal Vivo
Seatpost
Aluminium, 31,6 mm
Brakes
Shimano MT200, hydraulic disc brake
Brake lever
Shimano MT200
Brake
Disc
Rims
RODI TRYP25, 25-622
Rear hub
Shimano Alivio MT400, 12x148 mm
Front Hub
Shimano Alivio MT400, 15x110mm,Shimano Alivio MT400, 15x110 mm
Tires
Schwalbe Smart Sam, 57-584
Gears
9
Bike weight incl. battery in kg.
22,80 kg
Size
36,40
* Subject to technical modification without notice. Errors and omissions excepted.
** Weight in size M, of standard specification and without pedals.
