PLANET 6.7 Features
Robust and lightweight aluminium frame with diamond or trapezium frame design
Stylish and ideal for everyday riding: discreet mudguards and minimalist pannier rack
High-quality Shimano Deore/XT drive
Conquers the city
-
Carefree & Clean
No squeaking, no mud on your trouser legs and minimal maintenance requirements – all made possible thanks to the PLANET's hub gears and belt drive.
-
Consistent brake performance
You may love whizzing past stationary cars in the city, but you'll still have to brake at some point! The disc brakes enable perfectly controlled braking with consistent performance.
-
Prepared for anything
Mudguard and light ensure you're well equipped when you're out and about in bad weather or after dark.
Geometry
| S | M | L | XL | ||
|---|---|---|---|---|---|
| Size | 45 | 50 | 55 | 60 | |
| A | Size (MM) | 450 | 500 | 550 | 600 |
| B | Effective Top Tube (MM) | 570 | 580 | 595 | 610 |
| C | Head Tube Angle (°) | 71 | 71.5 | 71.5 | 71.5 |
| D | Effective Seat Tube Angle (°) | 74 | 73.5 | 73 | 72.5 |
| E | Chainstay (MM) | 465 | 465 | 465 | 465 |
| F | BB Drop (MM) | 60 | 60 | 55 | 55 |
| G | Head Tube Length (MM) | 135 | 135 | 170 | 220 |
| H | Fork Length (MM) | 465 | 465 | 465 | 465 |
| I | Fork Offset (MM) | 45 | 45 | 45 | 45 |
| J | Wheelbase (MM) | 1094 | 1093 | 1104 | 1113 |
| K | Stack (MM) | 621 | 624 | 652 | 699 |
| L | Reach (MM) | 392 | 395 | 396 | 390 |
Specification
Frame
6061 aluminium, Belt Drive ready, international disc brake standard
Fork
6061 aluminium
Shifter
Shimano Deore
Front derailleur
Shimano Deore
Rear derailleur
Shimano Deore XT
Sprocket description
Shimano HG500, 11-32T
Chain
Shimano CN-HG54
Crankset
ShimanoDeore, 48/36/26T
Handlebar
aluminium, flatbar
Grips
Ergon GX1
Stem
aluminium, 31.8mm
Saddle
Focus Urban
Seatpost
BBB, aluminium, 31,6 mm
Brakes
Shimano BR-MT200, 180 mm / 160 mm
Wheelset
Rodi Corsa 29" 662-23, Shimano DH3D37 / Shimano Deore, 9 mm QR / 9 mm QR
Tires
Schwalbe Marathon, 37-622
Fender
Büchel
Headlight
AXA Blueline, 30 Lux
Taillight
integrated in carrier
Rims
RODI AIRLINE CORSA GEÖST
Headset
VP Components
Bottom Bracket
BSA
Rear hub
Shimano Deore M6000, QR
Front Hub
Shimano DH-3D37 hub dynamo, QR
Gears
30
Transmission of drive
front: 48/36/26, rear: 11-32
Travel Fork
63 mm
Brake
Disc
Brake levers
Shimano MT200
* Subject to technical modification without notice. Errors and omissions excepted.
** Weight in size M, of standard specification and without pedals.
