CRATER LAKE 3.9

Geometry Specification
SKU
FO8040002v2019

CRATER LAKE 3.9 Features

Robust and lightweight aluminium frame with diamond or trapezium frame design

Control and comfort: SR Suntour NEX suspension fork with lockout

High shifting precision: Shimano Deore XT rear derailleur

Speedy all-rounder

  • The choice is yours

    The CRATER LAKE offers you a choice of two different frame shapes – step-through or Diamant frame.

  • Fully prepared

    The suspension fork and off-road tyres of the CRATER LAKE ensure that you are fully prepared for outings on gravel.

  • Pedal effortlessly uphill

    Three chain rings provide the optimum transmission ratio range to ensure that no hill is too steep.

Geometry

S M L XL
Size 45 50 55 60
A Size (MM) 450 500 550 600
B Effective Top Tube (MM) 570 580 595 610
C Head Tube Angle (°) 71 71.5 71.5 71.5
D Effective Seat Tube Angle (°) 74 73.5 73 72.5
E Chainstay (MM) 465 465 465 465
F BB Drop (MM) 60 60 55 55
G Head Tube Length (MM) 135 135 170 220
H Fork Length (MM) 465 465 465 465
I Fork Offset (MM) 45 45 45 45
J Wheelbase (MM) 1093 1092 1104 1114
K Stack (MM) 613 616 644 691
L Reach (MM) 394 398 398 392

Specification

Frame
6061 aluminium, international disc brake standard
Fork
SR Suntour NEX HLO DS, 63 mm travel, 9 mm QR
Shifter
Shimano Deore T6000
Front derailleur
Shimano Deore T6000
Rear derailleur
Shimano Deore XT M781, 10-speed
Sprocket description
Shimano HG500, 11-32T
Chain
KMC X10.93
Crankset
Shimano FC-T521, 48/36/26T
Handlebar
aluminium, riserbar, 680mm
Grips
Focus SL
Stem
aluminium, 31.8mm
Saddle
Focus Sport Saddle
Seatpost
fixed, aluminium, Ø 27.2
Brakes
Shimano BR-MT200, hydraulic disc
Wheelset
Rodi Viper 21, 29" 622-21, Shimano TX-505 CL, 9 mm QR / 9 mm QR
Tires
Schwalbe CX Comp, 40-622
Brake type
Disc
Transmission of drive
front: 48/36/26, rear: 11-32
Travel
63 mm
