ARRIBA 3.9

Geometry Specification
€799
SKU
FO8010008v2019

ARRIBA 3.9 Features

Robust and lightweight aluminium frame with diamond or trapezium frame design

Stylish and ideal for everyday riding: discreet mudguards and minimalist pannier rack

Reliable Shimano Claris drive components

Gets you off the couch and into gear

  • Prepared for anything

    Whether you're heading off on a long tour or training in the rain – no problem for our models fitted with a pannier rack and mudguard.

  • The choice is yours

    And to ensure your workout is as comfortable as possible, we offer two frame geometries – trapezium or diamond.

  • Consistent brake performance

    Our ARRIBAs are equipped with disc brakes to help you keep control even when travelling at top speeds.

Geometry

S M L XL
Frame size cm 45 50 55 60
A Size (MM) 450 500 550 600
B Effective Top Tube (MM) 569 584 598 612
C Head Tube Angle (°) 70.5 70.5 70.5 70.5
D Effective Seat Tube Angle (°) 72.5 72.5 72.5 72.5
E Chainstay (MM) 434 434 434 434
F BB Drop (MM) 62 62 62 62
G Head Tube Length (MM) 155 170 185 185
H Fork Length (MM) 395 395 395 395
I Fork Offset (MM) 46 46 46 46
J Wheelbase (MM) 1047 1063 1077 1091
K Stack (MM) 568 582 596 606
L Reach (MM) 390 400 410 420

Specification

Frame
Arriba, aluminium 6061, disc, BSA BB, 135 mm quick release dropouts, post mount 160 mm, internal brake & gear cable routing
Fork
Arriba, aluminium, disc, 100 mm quick release, post mount 160 mm
Shifters
Shimano Claris SL2000
Front derailleur
Shimano Claris 2000, w/clamp 31.8
Rear derailleur
Shimano Claris 2000, 8-speed, short cage
Sprocket description
Shimano HG200, 12-32T
Chain description
Sram NX Eagle
Crankset description
Shimano Claris 2000, 50/34T
Handlebar
Concept EX, aluminium, flat
Grip/Tape description
Velo VLG-1389
Stem
Concept, aluminium, 31.8mm, +/- 6degree
Saddle description
Velo VL-3363 Steel Rail,Prologo Dimension
Seatpost
Concept, aluminium, 27,2 mm, 350 mm, set-back: 15mm
BrakeSystem
Shimano BR-MT200, hydraulic disc
Wheelset
Concept aluminium, 28", 622-21, Shimano TX-505 CL, 9 mm QR / 9 mm QR
Tire Description
Continental Contact Speed, 28-622
Fender description
Pletscher Sport, Alloy, 35 mm
Brake type
Disc
Transmission of drive
front: 50/34, rear: 12-32
