Exemplary bike presentation. Actual parts are shown in the specifications list.
Conquers new mountains
-
Lightweight and sexy
Thanks to its low weight, the JAM² can climb every mountain – and it will do it in style. The e-drive is perfectly integrated into the down tube and very little energy is wasted thanks to the low weight of the bike.
-
Optimal suspension performance in any situation
Our F.O.L.D. chassis has been specially designed to meet the increased demands placed on e-MTBs. This means that we can also guarantee the perfect mix for the e-All-Mountain JAM²: F.O.L.D. is extremely sensitive while being progressive enough to prevent a harsh bottom out.
-
Handling characteristics matter
We use only those drives and batteries that enable us to create a modern, agile and aggressive geometry for the JAM² thanks to their compact construction. This means that you will have just as much fun out on the trail as with our non-electric JAM.
Geometry
| S | M | L | ||
|---|---|---|---|---|
| Size | 41 | 44 | 47 | |
| Size (MM) | 410 | 440 | 470 | |
| Handlebar width | 760 | 760 | 760 | |
| Stem Length (MM) | 55 | 55 | 55 | |
| Crankarm length | 165 | 165 | 165 | |
| A | Seat tube length (MM) | 410 | 440 | 470 |
| B | Effective Top Tube (MM) | 582 | 602 | 622 |
| C | Head Tube Angle (°) | 66,1 | 66,1 | 66,1 |
| D | Effective Seat Tube Angle (°) | 74,1 | 74,1 | 74,1 |
| E | Chainstay length (MM) | 470 | 470 | 470 |
| F | Bottom bracket drop (MM) | 16,5 | 16,5 | 16,5 |
| G | Head Tube Length (MM) | 120 | 120 | 140 |
| H | Fork construction height (MM) | 561 | 561 | 561 |
| I | Pre-raked fork (MM) | 51 | 51 | 51 |
| J | Wheelbase length (MM) | 1198 | 1218 | 1233 |
| K | Stack (MM) | 620 | 620 | 638 |
| L | Reach (MM) | 405 | 425 | 440 |
Specification
Frame
Carbon front triangle, 7005 aluminium rear triangle, 3D forging, 150 mm F.O.L.D. kinematics, 148x12 mm thru axle, internal cable routing, post mount 180 mm
Frame material
Carbon
Fork
Rock Shox Revelation RC, 110x15 mm QR, 150 mm travel
Travel Fork
150 mm
Shock
Rock Shox Deluxe R, 210/55 mm, hardware: 25,0 x 8mm, custom tune
Motor
Shimano Steps E8000, 70 Nm, 250 W
Battery Watt-hours
756 Wh (378 Wh internal, 378 Wh external T.E.C. Pack)
Battery Ampere hours
10,5 Ah
Display
Shimano Steps E8000, colored LCD display, walk assist, bluetooth
Shifter
Shimano XT 8000
Rear derailleur
Shimano Deore XT 8000, 11-speed
Sprocket
Shimano SLX CSM7000 11-S 11-46T
Chain
Shimano CN-HG601, 11-speed
Crankset
FC-E8050-34T Hollow
Transmission of drive
front: 34, rear: 11-46
Bottom Bracket
Integrated in Drive Unit
Handlebar
BBB, aluminium, Di2, flatbar, 760mm, rise: 0mm, backsweep: 9degree
Grips
BBB Cobra BHG-96
Stem
BBB, aluminium, Di2, 31.8 mm, 55 mm
Headset
ACROS AIX-322, tapered, IS 42/286-IS52/40
Saddle
FOCUS Trail Saddle
Seatpost
KindShock E30i, 31,6mm, internal
Brakes
Shimano BR-M520, 200 mm / 200 mm
Brake
Disc
Rims
RaceFace AR30 Offset
Wheelset
Race Face AR30, 622-30, Novatec, 148x12 mm / 110x15 mm
Rear hub
Novatec D162 Disc, 12x148 mm
Front Hub
Novatec D041, 15x110 mm
Tires
Maxxis Rekon 2.6 3C EXO TR
Gears
11
Size
44,47,41
* Subject to technical modification without notice. Errors and omissions excepted.
** Weight in size M, of standard specification and without pedals.
