Riding together from the outset
-
A perfect fit for young riders
It's only fun mountain biking if the bike is right. The adapted geometry of our JUNIOR bikes offers the same ride characteristics as its adult counterpart. With the exception of its 26" wheels – junior wheels for a junior bike.
-
Unites young and old
More fun for the whole family. The SQUARED EXPERIENCE makes it possible to coordinate a range of performance classes. 378 Wh extra makes for a fun bike ride together.
-
It's the ride characteristics that count
Thanks to the compact design of the Shimano E8000 motor and our battery, we were able to create a super agile geometry for the JAM² HT JUNIOR. For a whole load of fun on the trail.
Geometry
| XS | ||
|---|---|---|
| Size | 35 | |
| Size | 350 | |
| Handlebar width | 700 | |
| Stem Length | 55 | |
| Crankarm length | 170 | |
| A | Seat tube length | |
| B | Effective Top Tube | 544 |
| C | Head Tube Angle | 67.5 |
| D | Effective Seat Tube Angle | 74 |
| E | Chainstay length | 425 |
| F | Bottom bracket drop | 45 |
| G | Head Tube Length | 110 |
| H | Fork construction height | 473 |
| I | Pre-raked fork | 39 |
| J | Wheelbase length | 1063 |
| K | Stack | 571 |
| L | Reach | 380 |
Specification
Frame
7005 hydroformed aluminium, 3D forging, 148x12 mm thru axle, internal cable routing, post mount 180 mm, kickstand mount 18 mm
Frame material
Aluminium
Fork
Rock Shox Recon TK, 100x15 mm QR, 100 mm travel
Travel Fork
80 mm
Motor
Shimano Steps E8000, 70 Nm, 250 W
Battery Watt-hours
378 Wh
Battery Ampere hours
10,5 Ah
Display
Shimano Steps E8000, colored LCD display, walk assist, bluetooth
Shifter
Shimano Deore M6000
Rear derailleur
Shimano Deore M6000
Sprocket
Shimano HG500
Chain
Shimano CN-HG54
Crankset
Shimano Steps
Transmission of drive
front: 34, rear: 11-42
Handlebar
BBB, aluminium, Di2, flatbar, 700mm, rise: 10mm, backsweep: 9degree
Grips
FOCUS Locker SL
Stem
BBB, aluminium, Di2, 31.8 mm, 45 mm
Headset
VP Components
Saddle
FOCUS Trail SL
Seatpost
BBB-BSP-20, 31.6 mm, 350mm
Brakes
Shimano MT200, hydraulic disc brake
Brake lever
Shimano MT200
Brake
Disc
Wheelset
Schürmann Yak 21 Disc, 26" 559-21, Novatec, 148x12 mm / 110x15 mm
Rims
Schürmann YAK 21
Rear hub
Novatec D162 Disc, 12x148 mm
Front Hub
Novatec D041SB, 15x100 mm
Tires
Schwalbe Tough Tom 2.25
Gears
10
Size
35
* Subject to technical modification without notice. Errors and omissions excepted.
** Weight in size M, of standard specification and without pedals.
