PARALANE² 9.6

Geometry Specification
SKU
FO5080035v2019

PARALANE² 9.6 Features

Revolutionary F.I.T. carbon frame with carbon fork and Comfort Improving Areas (C.I.A.), Curana mudguards for clever installation and R.A.T. floating axle

Support just when you need it: 400 Watt extra power thanks to the Fazua Evation system

Long service life and reliable gear shifting: Shimano 105

Support at the right moment

  • Combines the advantages of racing bikes and E-bikes

    Light and agile, but with an extra push, when support is needed: the removable motor/battery unit is decoupled from the drive and only noticeable when it makes the ride easier.

  • More tyre clearance offers greater freedom

    The maximum tyre clearance of up to 35 mm gives you the freedom to ride on any type of surface – whether asphalt or gravel tracks.

  • Optimum gearshift

    Our pioneering road-boost standards with wide 148 and 110 mm R.A.T. axles ensure an optimum chain line on e-racing bikes – which in turn ensures an optimum gearshift and less wear and tear.

Geometry

S M L XL
Frame size cm 51 54 57 60
A Size (MM) 480 516 540 570
B Effective Top Tube (MM) 524 547 568 590
C Head Tube Angle (°) 71.5 72 72.5 72.5
D Effective Seat Tube Angle (°) 74.5 73.5 73.5 73.5
E Chainstay (MM) 415 415 415 415
F BB Drop (MM) 75 75 75 75
G Head Tube Length (MM) 150 165 190 215
H Fork Length (MM) 380 380 380 380
I Fork Offset (MM) 46 46 46 46
J Wheelbase (MM) 990 996 1014 1036
K Stack (MM) 564 580 605 630
L Reach (MM) 370 375 390 405

Specification

Display
FAZUA evation 1.0 remote
Motor
FAZUA evation, 60 Nm, 250 W
Battery Ampere hours
7 Ah
Battery Watt-hours
250 Wh
Frame
Carbon SL E-Road, disc, road boost 148x12 mm through axle, RAT Evo technology, flat mount 160 mm, internal brake & gear cable routing
Fork
Carbon, disc, road boost 110x12 mm RAT through axle, RAT Evo Technology, flat mount 140 mm, internal brake cable routing
Handlebar
BBB Basic, Aluminium, drop: 125 mm, reach: 70mm
Saddle description
Prologo Scratch
Seatpost
BBB CPX Plus, Carbon, 27,2mm, 350mm, set-back: 20mm
Stem
BBB Basic, aluminium, 31.8mm, +/- 7 degree
Tire Description
Continental Ultra Sport II, 700 x 28C
Bike weight incl. battery in kg.
12345 kg
Brake levers
Shimano 105 R7025
BrakeSystem
Shimano 105 R7025 hydraulic disc
Brake type
Disc
Crankset description
FSA, aluminium
Rear derailleur
Shimano 105 R7000
Shifters
Shimano 105 R7020
Sprocket description
Shimano 105, 11-34T
Transmission of drive
front: 50/34, rear: 11-34
Wheelset
DT Swiss RR521 SPLINE DB, 32mm height w/ DT Swiss 370 boost hub
Chain description
Shimano CN-HG601
Fender description
Curana C-Lite
Grip/Tape description
Focus Bartape SL
