AVENTURA² 6.8

Geometry Specification
SKU
FO5080053v2019

AVENTURA² 6.8 Features

Ready for any adventure: high-performance Bosch Performance CX motor

Perfect fit: 29" wheels from frame size S upwards, 27.5" wheels for frame size XS and S

Durable Shimano Deore 10-speed drive

Geometry

XS S M L XL
Size 36 40 44 48 52
A Size (MM) 360 400 440 480 520
B Effective Top Tube (MM) 554 578 588 608 623
C Head Tube Angle (°) 69 70 70 70 70
D Effective Seat Tube Angle (°) 73.5 74 74 74 74
E Chainstay (MM) 475 490 490 490 490
F BB Drop (MM) 48 60 60 60 60
G Head Tube Length (MM) 120 120 120 140 160
H Fork Length (MM) 489 509 509 509 509
I Fork Offset (MM) 42 51 51 51 51
J Wheelbase (MM) 1106 1145 1155 1177 1194
K Stack (MM) 604 636 636 655 674
L Reach (MM) 375 395 405 420 430

Specification

Frame
6061 aluminium, internal cable routing, international disc brake standard
Fork
SR Suntour Raidon 32 RLR DS, 15 x 110 mm QR, lockout
Motor
Bosch Performance CX, 75 Nm, 250 W, 50-300% support power
Shifter
Shimano Deore
Rear derailleur
Shimano Deore
Sprocket description
Shimano HG500, 11-42T
Chain
Shimano CN-HG54
Crankset
FSA CK-745
Handlebar
aluminium, riserbar, 720mm
Grips
Ergon GP10
Stem
aluminium, 31.8mm
Saddle
Focus Sport Saddle
Seatpost
BBB, aluminium, 31,6 mm
Brakes
Shimano MT435, 180 mm / 180 mm
Wheelset
Shimano MT500
Tires
Continental X King, 55-622
Fender
Büchel
Headlight
Hermans Berleen
Display
BOSCH Purion with Control panel, walk assist
Travel
100 mm
Transmission of drive
front: 18, rear: 11-42
Battery Watt-hours
500 Wh
Battery Ampere hours
13,4 Ah
Brake type
Disc
