PLANET² 6.8

Geometry Specification
SKU
FO5080058v2019

Practical in the city

  • Ready for anything

    Pannier rack, mudguards, lighting system, chain guard, stand – the PLANET² offers a long and comprehensive list of features.

  • Clean and dry

    Thanks to its matching mudguards, you and your clothes will remain clean and dry.

  • Perfectly integrated battery

    Our perfectly integrated battery is concealed in the down tube, yet it can be removed at any time.

Geometry

S M L XL
Size 43 48 53 58
Size (MM) 430 480 530 580
Handlebar width 700 700 700 700
Stem Length (MM) 80 80 80 80
Crankarm length 170 170 175 175
A Seat tube length
B Effective Top Tube (MM) 588 597 606 615
C Head Tube Angle (°) 72 72 72 72
D Effective Seat Tube Angle (°) 73 73 73 73
E Chainstay length (MM) 485 485 485 485
F Bottom bracket drop (MM) 65 65 65 65
G Head Tube Length (MM) 160 170 180 190
H Fork construction height (MM) 470 470 470 470
I Pre-raked fork (MM) 45 45 45 45
J Wheelbase length (MM) 1107 1117 1126 1135
K Stack (MM) 648 658 667 677
L Reach (MM) 390 396 402 408

Specification

Frame
6061 aluminium, internal cable routing
Frame material
Aluminium
Fork
SR Suntour NEX E25, lockout, 15mm QR,Rigid fork, alloy
Travel Fork
63 mm
Motor
Bosch Performance CX, 75 Nm, 250 W, 50-300% support power
Battery Watt-hours
500 Wh
Battery Ampere hours
13,4 Ah
Display
BOSCH Purion with Control panel, walk assist
Shifter
Shimano Deore
Rear derailleur
Shimano SLX
Sprocket
Shimano HG500
Chain
Shimano CN-HG54
Crankset
FSA CK-310
Bottom Bracket
Integraded in Drive Unit
Transmission of drive
front: 18, rear: 11-34
Handlebar
aluminium, flatbar
Grips
Ergon GX1
Stem
aluminium, 31.8mm
Headset
VP Components
Saddle
FOCUS Urban
Seatpost
BBB, aluminium, 31,6 mm
Brakes
Shimano MT400, 180 mm / 180 mm
Brake lever
Shimano MT400
Brake
Disc
Wheelset
Rodi Corsa 29" 662-23, Shimano Deore, 148x12 mm / 110x15 mm
Rims
RODI AIRLINE CORSA DOPPELT GEÖST
Rear hub
Shimano Acera M3050, QR
Front Hub
Shimano Deore M6010, 15x100 mm
Tires
Continental Contact Speed, 42-622,Schwalbe Supermoto X, 62-584
Fender
Tubus Wingee
Headlight
Busch & Müller Avy, 40 Lux
Taillight
Hermans rear light, integrated
Gears
10
Size
53,43,48,58
* Subject to technical modification without notice. Errors and omissions excepted. ** Weight in size M, of standard specification and without pedals.
