FOCUS O1E 8.8

Geometry Specification
SKU
FO3150005v2019

FOCUS O1E 8.8 Features

Lightweight carbon frame with F.O.L.D. kinematics and R.A.T. floating axle

Fox 32 Rhythm suspension fork with 120 mm suspension travel and Fox Float DPS Performance shock

Sram NX Eagle 1x12 drive with wide gear ratio range

Shifts racing requirements

  • Loved by professionals

    XC world-class athletes oversaw the development of the FOCUS O1E – ensuring that the highest demands were met.

  • Optimum suspension performance for every situation

    The F.O.L.D. kinematics specially tailored to the demands of cross-country helps you push the boundaries and reach the finish line faster.

  • Sets the benchmark in lightweight construction

    The extremely lightweight frame and kinematics make every uphill climb a breeze.

Geometry

S M L
A Size (MM) 422 445.8 482.2
B Effective Top Tube (MM) 584 602 623
C Head Tube Angle (°) 69.2 69.2 69.2
D Effective Seat Tube Angle (°) 74.5 74.5 74.5
E Chainstay (MM) 448 448 448
F BB Drop (MM) 38 38 38
G Head Tube Length (MM) 100 112 125
H Fork Length (MM) 511 511 511
I Fork Offset (MM) 46 46 46
J Wheelbase (MM) 1127 1146 1167
K Stack (MM) 598 605 622
L Reach (MM) 419 435 450

Specification

Frame
Carbon frame, 100 mm F.O.L.D. kinematic, PF30 BB, 148x12 mm through axle, internal cable routing, Post Mount 160 mm
Fork
Fox 32 Rhythm, sweep adjust, 15 mm QR, 120 mm travel
Handlebar
BBB, aluminium, flatbar, 720mm, rise: 0mm, backsweep: 9degree
Saddle
Focus Race SL
Seatpost
BBB, aluminium, 31,6 mm
Stem
BBB Race, aluminium, 31.8 mm
Tire
Schwalbe Racing Ralph Performance 2.25
Brake levers
SRAM LEVEL TL
BrakeSystem
Sram Level TL, 180 mm / 160 mm
Brake type
Disc
Crankset
Sram Stylo 6K, 32T
Rear derailleur
Sram NX, 12-speed
Shifters
Sram NX Eagle
Rear shock
Fox Float DPS Performance, 3-position lever, 165/38 mm, hardware: 22,2 x 8mm, custom tune
Sprocket
Sram PG-1230 Eagle, 10-50T
Gear ratio
front: 32, rear: 10-50
Travel
120 mm
Wheelset
DT Swiss M1900, 622-25
