IZALCO MAX DISC 9.8

Geometry Specification
SKU
FO0010018v2019

IZALCO MAX DISC 9.8 Features

Aerodynamically shaped, lightweight carbon frame with carbon handlebar stem and integrated cable routing, disc brakes and R.A.T. floating axles

Cable-free, maximum shifting performance: Sram Red eTap

Ultra-fast DT Swiss ARC1450 DICUT carbon wheelset

More than just the fastest

  • Optimised in the wind tunnel

    The balanced proportions of the frame, which incorporates MAX Carbon Technology and elegant tubes with Kammtail profiles, provide the ultimate combination of aerodynamics and low weight. When combined with integrated cables and our aero stem and aero seat posts, we offer as little wind resistance as possible.

  • To sum up, it is simply faster

    Go faster for longer thanks to increased comfort: The 15 mm offset of the aerodynamic carbon seat post provides perfect ergonomics and comfort. However, since the seat tube of the IZALCO MAX has been offset in the forward direction, the effective offset is just 2 mm. As a result, you can enjoy complete comfort while at the same time riding in a modern racing sitting position.

  • More than just the fastest

    The IZALCO MAX is a statement. It provides more than just aerodynamics, low weight and incredible speeds. It combines all its skills to create a thrilling riding experience that will compel you to go out on more rides with your pals. Get more out of it together. With more style, elegance and dedication.

Geometry

XXS XS S M L XL XXL
Frame size cm 47 50 52 54 56 58 61
A Size (MM) 430 470 490 510 530 550 590
B Effective Top Tube (MM) 504 517 535 551 564 582 602
C Head Tube Angle (°) 69.5 70.5 71.5 72 72 72.5 72.5
D Effective Seat Tube Angle (°) 74 73.5 73.5 73.5 73.5 73.5 73.5
E Chainstay (MM) 410 410 410 410 410 410 410
F BB Drop (MM) 78 78 78 78 78 78 78
G Head Tube Length (MM) 80 80 100 115 125 150 185
H Fork Length (MM) 392 392 392 392 392 392 392
I Fork Offset (MM) 46 46 46 46 46 46 46
J Wheelbase (MM) 975 975 985 997 1010 1024 1044
K Stack (MM) 502 506 528 544 554 579 613
L Reach (MM) 360 368 378 390 400 410 420

Specification

Frame
MAX technology carbon, disc, BB86, 142x12 mm through axle, RAT Evo technology, electronical shifting only, flat mount 160 mm, internal cable routing
Fork
MAX technology carbon, integrated, disc, 100x12 mm RAT through axle, RAT Evo Technology, flat mount 160/140 mm, internal brake cable routing
Shifters
SRAM Red eTap
Front derailleur
SRAM Red eTap
Rear derailleur
Sram Red eTap
Sprocket description
Sram XG-1190, 11-28T
Chain description
SRAM RED22
Crankset description
Sram Red, 52/36T
Handlebar
Easton EC90 Aero, carbon, drop: 125mm, reach: 80mm
Grip/Tape description
Focus Bartape SL
Stem
Izalco Max carbon, integrated cable routing, 31.8mm, -15 degree
Saddle description
Prologo Dimension
Seatpost
Izalco Max aero carbon, D-shape, 350 mm, set-back: 15mm
BrakeSystem
Sram Red eTap hydraulic disc, 160 / 160 mm
Wheelset
DT Swiss ARC 1450 DICUT DB, 48mm height
Tire Description
Continental GP4000S II, 700 x 25C, Folding
Brake type
Disc
Transmission of drive
front: 52/38, rear: 11-28
