RAVEN Junior

Geometry Specification
SKU
FO3050005v2018

RAVEN Junior Features

Small-design, 26" RAVEN aluminium frame

Lightweight aluminium rigid fork

Shimano M315 disc brakes

Going for gold from the outset

  • A perfect fit for young riders

    It's only fun mountain biking if the bike is right. The adapted geometry of our JUNIOR bikes offers the same ride characteristics as its adult counterpart. With the exception of its 26" wheels – junior wheels for a junior bike.

  • As tough as necessary, as light as possible

    A mountain bike for teenagers needs to be tough as well as easy to manoeuvre. Which is why we've made the RAVEN JUNIOR: as tough as necessary, as light as possible.

  • As simple as possible

    The rigid fork on the RAVEN JUNIOR ensures super acceleration, that no power is lost and that the bike is low-maintenance.

Geometry

XS
A Size 360
B Effective Top Tube 528
C Head Tube Angle 69
D Effective Seat Tube Angle 73.5
E Chainstay 430
F BB Drop 38
G Head Tube Length 105
H Fork Length 451.5
I Fork Offset 35
J Wheelbase 1027
K Stack XS
L Reach XS

Specification

Frame
6061 aluminium, BSA BB
Fork
Rigid fork, alloy
Handlebar
aluminium, riserbar
Saddle
Focus Sport Saddle
Seatpost
fixed, aluminium, Ø 27.2
Stem
aluminium, 31.8mm
Tire
Schwalbe Rocket Ron, 54-559
BrakeSystem
Shimano M315, 160 mm / 160 mm
Brake type
Disc
Chain ring
1x
Crankset
Prowheel Single, SQ, 32T
Rear derailleur
Shimano Altus, 9-speed
Seatpost type
Fixed seatpost
Shifters
Shimano Altus
Shifting type
Mechanical shifting
Sprocket
Shimano HG200, 11-36T
