No obstacle is too great
-
Optimal suspension performance in any situation
The F.O.L.D. chassis with 170 mm travel, which has been specially tuned to meet the demands of Enduro riding, provides a perfectly balanced mix: F.O.L.D. is extremely sensitive while being progressive enough to prevent a harsh bottom out. And there is still enough space for a bottle cage.
-
Lightweight and sturdy
The lightweight carbon frame with aluminium rear triangle only weights 2840 g and provides a great balance between low weight and strength. Advanced trail riding is no problem thanks to the perfect mix of high modulus and high strength carbon fibres as well as the sturdy aluminium rear triangle. Our tests ensure maximum strength significantly above the standard.
-
Nimble and sturdy
The SAM rolls on 27,5" wheels. As a result, the SAM rides agile and nimble even when cornering sharply. Especially when the terrain gets rougher, the 27,5" wheels offer an extra on stability for your enduro ride.
Geometry
| S | M | L | ||
|---|---|---|---|---|
| Size | 41 | 44 | 46 | |
| Size (MM) | 400 | 425 | 450 | |
| Handlebar width | 760 | 760 | 760 | |
| Stem Length (MM) | 45 | 45 | 45 | |
| Crankarm length | 170 | 170 | 170 | |
| A | Seat tube length (MM) | 125 | 150 | 170 |
| B | Effective Top Tube (MM) | 581 | 603 | 623 |
| C | Head Tube Angle (°) | 64.8 | 64.8 | 64.8 |
| D | Effective Seat Tube Angle (°) | 75 | 75 | 75 |
| E | Chainstay length (MM) | 428 | 428 | 428 |
| F | Bottom bracket drop (MM) | 13 | 13 | 13 |
| G | Head Tube Length (MM) | 106 | 115 | 130 |
| H | Fork construction height (MM) | 562 | 562 | 562 |
| I | Pre-raked fork (MM) | 42 | 42 | 42 |
| J | Wheelbase length (MM) | 1170 | 1195 | 1221 |
| K | Stack (MM) | 600 | 610 | 623 |
| L | Reach (MM) | 420 | 440 | 460 |
Specification
Frame
Carbon front and alloy rear triangle, 170mm F.O.L.D. kinematic, ISCG 05, PF30 BB, 148x12 thru axle, internal cable routing, Post Mount 180 mm
Frame material
Carbon
Fork
Rock Shox Yari RC 27.5 Boost, DebonAir, 110x15 mm, 37 mm rake, 170 mm travel
Travel Fork
170 mm
Shock
FOX Float DPX2 Performance, 3-position lever, 230/65 mm, hardware: 30,0 x 8 mm, custom tune
Shifter
SRAM SX Eagle, 12-speed
Rear derailleur
SRAM SX Eagle, 12-speed
Sprocket
SRAM PG-1230 Eagle, 12-speed
Chain
SRAM SX Eagle, 12-speed
Crankset
SRAM SX Eagle
Bottom Bracket
PF92 BB
Transmission of drive
front: 32, rear: 10-50
Handlebar
BBB Ascension BHB-110, aluminium, riserbar, 780mm, rise: 20mm, backsweep: 9degree
Grips
FOCUS Locker SL
Stem
BBB Jumper BHS-138, 31.8 mm
Headset
Acros AIX-322, tapered, IS 42/286-IS52/40
Saddle
FOCUS Trail SL
Seatpost
Kind Shock E30i, 31,6mm
Brakes
SRAM Guide R
Brake lever
SRAM Guide R
Brake
Disc
Rims
RaceFace AR30 Offset
Rear hub
Novatec D162 Disc, 12x148 mm
Front Hub
Novatec D041, 15x110 mm thru axle
Tires
Maxxis Minion DHF 2.5 Dual Exo TR
Gears
12
Bike weight incl. battery in kg.
15,15 kg
Size
41,44,46
* Subject to technical modification without notice. Errors and omissions excepted.
** Weight in size M, of standard specification and without pedals.
