PLANET² 5.9

Geometry Specification
SKU
FO5080057v2020

PLANET² 5.9 Features

Dynamic: The new Bosch Performance drive

Elegant and protected: Removable 625 Wh battery integrated into the down tube

Robust Shimano drive components and highly stable metal mudguards

Fully equipped

  • Prepared for anything

    Pannier rack, mudguards, lighting system, chain guard, bike stand – the list of equipment for the PLANET² is long and comprehensive.

  • Dry & Clean

    Matching mudguards keep you and your clothes clean and dry.

  • The integrated battery ensures a sleek design

    Our battery is discreetly integrated in the down tube and can be removed at any time (excluding the top-of-the-range model).

Geometry

S M L XL
Frame size cm 43 48 53 58
A Size (MM) 430 480 530 580
B Effective Top Tube (MM) 588 597 606 615
C Head Tube Angle (°) 72 72 72 72
D Effective Seat Tube Angle (°) 73 73 73 73
E Chainstay (MM) 485 485 485 485
F BB Drop (MM) 65 65 65 65
G Head Tube Length (MM) 160 170 180 190
H Fork Length (MM) 468 468 468 468
I Fork Offset (MM) 45 45 45 45
J Wheelbase (MM) 1107 1117 1126 1135
K Stack (MM) 648 658 667 677
L Reach (MM) 390 396 402 408

Specification

Frame
6061 aluminium, internal cable routing
Fork
SR Suntour NEX E25, lockout, 9mm QR
Motor
Bosch Performance Gen3, 65 Nm, 250 W
Shifters
Shimano Altus M2010
Rear derailleur
Shimano Alivio M4000
Chain description
Shimano CN-HG53
Crankset description
FSA CK-310
Handlebar
Aluminium, riserbar, backsweep: 15 degree, 690mm
Grip/Tape description
Ergon GP10
Stem
Focus aluminium, 31,8 mm, 60 mm, 17 degree
Saddle description
Touring
Seatpost
Aluminium, 27,2 mm
BrakeSystem
Shimano MT200, hydraulic disc brake
Tire Description
Schwalbe Energizer Active Plus, 47-622
Fender description
Tubus Wingee
Front light type
Herrmans H-Black MR8, LED
Rear light type
Herrmans H-Trace Micro
Bike weight incl. battery in kg.
24,7 kg,24,6 kg
Travel
63 mm
Display
Bosch Purion
Brake type
Disc
Battery Watt-hours
600 Wh
Battery Ampere hours
17,3 Ah
Brake levers
Shimano MT200
