FOCUS O1E 8.7 Features
Lightweight carbon frame with trail-oriented downhill geometry and R.A.T. quick release axle
Trail-oriented F.O.L.D. Chassis: 120 mm Fox 32 Rhythm suspension fork and 110 mm Fox Float DPS damper
Simple Sram NX Eagle shifter and easy-to-control Sram Level brakes
Shifts racing requirements
-
Loved by professionals
XC world-class athletes oversaw the development of the FOCUS O1E – ensuring that the highest demands were met.
-
Optimum suspension performance for every situation
The F.O.L.D. kinematics specially tailored to the demands of cross-country helps you push the boundaries and reach the finish line faster.
-
Sets the benchmark in lightweight construction
The extremely lightweight frame and kinematics make every uphill climb a breeze.
Geometry
| S | M | L | ||
|---|---|---|---|---|
| Frame size cm | 42 | 45 | 48 | |
| A | Size (MM) | 422 | 445.8 | 482.2 |
| B | Effective Top Tube (MM) | 589 | 605 | 625 |
| C | Head Tube Angle (°) | 68.4 | 68.4 | 68.4 |
| D | Effective Seat Tube Angle (°) | 74.2 | 74.2 | 74.2 |
| E | Chainstay (MM) | 448 | 448 | 448 |
| F | BB Drop (MM) | 31.5 | 31.5 | 31.5 |
| G | Head Tube Length (MM) | 100 | 112 | 125 |
| H | Fork Length (MM) | 531 | 531 | 531 |
| I | Fork Offset (MM) | 51 | 51 | 51 |
| J | Wheelbase (MM) | 1139 | 1158 | 1179 |
| K | Stack (MM) | 604 | 611 | 628 |
| L | Reach (MM) | 410 | 426 | 441 |
Specification
Frame
Carbon frame, F.O.L.D. kinematic, PF30 BB, 148x12 mm through axle, internal cable routing, Post Mount 160 mm
Fork
Fox 32 Rhythm, sweep adjust, 110x15 mm QR, 120 mm travel
Rear shock
Fox Float DPS Performance, 3-position lever, 165/38 mm, hardware: 22,2 x 8mm, custom tune
Shifters
Sram NX Eagle, 12-speed
Rear derailleur
Sram NX Eagle, 12-speed
Chain description
Sram NX Eagle
Crankset description
Truvativ Stylo 6K
Handlebar
Aluminium, riserbar, 760mm
Grip/Tape description
Focus Locker SL
Stem
BBB Jumper BHS-138
Saddle description
Focus Race SL
Seatpost
BBB Deluxe, Aluminium, 31,6mm, 350mm
BrakeSystem
SRAM Level TL
Wheelset
DT Swiss M1900, 622-25, 15x110 MM / 12x148 MM
Tire Description
Schwalbe Nobby Nic Performance Addix 2.35
Bike weight incl. battery in kg.
12,60 kg
Brake levers
SRAM LEVEL TL
Brake type
Disc
Travel
120 mm
