Practical in the city
Powerful e-motor for everyday use
The efficient Bosch Performance CX e-drive (Gen. 4) supports your ride up to 25 km/h with powerful 85 Nm. The strongest e-motor of Bosch is perfectly integrated, the PLANET²'s geometry is well-balanced and offers safety and reliability. The Bosch Powertube battery is perfectly integrated into the down tube, yet it can also be removed at any time for charging. For sure, you can also charge it directly on the bike. Thanks to 625 Wh battery capacity, you have more than enough range for your long tours.
A frame shape fitting your needs and more load
You are free to choose a wave or a diamond frame with the PLANET² - as you prefer. Furthermore, it is approved for 150 kg of maximum total weight, so you can also mount a trailer. That makes it ready for daily life challenges.
Safety and comfort
Disc brakes, lighting system and a comfortable seating position offer reliability. On top, the Planet² has 57 mm extra-wide off-road tyres that offer nice rolling behaviour, comfort, grip and safety even on unpaved roads.
|Stem Length (MM)||80||80||80||80|
|Seat post length (MM)||350||350||350||350|
|A||Seat tube length (MM)||430||480||530||580|
|B||Effective Top Tube (MM)||597||601||609||618|
|C||Head Tube Angle (°)||71||71||71||70.5|
|D||Effective Seat Tube Angle (°)||73||73||73||73|
|E||Chainstay length (MM)||494||494||494||494|
|F||Bottom bracket drop (MM)||65||65||65||65|
|G||Head Tube Length (MM)||160||170||180||190|
|H||Fork construction height (MM)||484||484||484||484|
|I||Pre-raked fork (MM)||44||44||44||44|
|J||Wheelbase length (MM)||1136||1140||1149||1164|
